Help Center2015 Hot Sale Swept-body Refuse Collector
Related Products
Main Technical Parameters | |||
Model |
Dongfeng pointed Gasoline arm type garbage truck |
Dimension |
7185*2470*3015 (mm) |
Chassis type |
DLQ5092 |
Cargo body size |
** (mm) |
Total mass |
9550 (kg) |
Appearance / departure angle |
34/14 (°) |
Rated payload |
4000(kg) |
F/R suspension |
1065/2170 (mm) |
Kerb weight |
5355 (kg) |
Maximum speed |
85 (km/h) |
Engine |
EQ6100-1 |
||
Displacement |
5420 (ml) |
Power |
99 (kw) |
Manufacturer |
Dongfeng Automobile Co., Ltd. commercial vehicle engine plant |
||
Emission standard |
GB14762-2002 |
||
Number of the axles |
2 |
Front tread |
1810 (mm) |
Wheel base |
3950 (mm) |
Rear tread |
1800 (mm) |
Number of the tires |
6 |
Tire type |
9.00-20 |
Fuel type |
Diesel |
Number of the springs |
8/11+8 |
Axle load |
2580/6970 |
Cab Passengers |
3 |
Others |
Only EQ6100-1 engine ,9.00-20 tires. Swing arm type garbage truck garbage bucket can be characterized by hanging from the crane, the arm, a working cycle time: 60S. The car is characterized by separate cargo compartment with the body, to achieve a vehicle with a number of co-operation cargo compartment, recycling transportation, to fully enhance the vehicle's transport capacity, especially for short-distance transport, such as the sanitation sector to urban garbage clean-up and transportation. Basic configuration: Pointed 140 EFI gasoline engine, 900 tire, box length 4.05m, Private Function Description:
Main technical parameters Chassis Type: EQ1092F19DJ second-class Dongfeng Automobile Co., Ltd. Other: 1, Yuchai YC4E140-20 engine (143PS) ,9.00-20 12PR tires. 2, the election of Dongfeng EQ1092FJ gasoline engine chassis. 3, the garbage bucket size (L * W * H): 3000 * 1900 * 1300 (mm) / provided by size according to your production, there is the ground type, to pit the two forms of spam fighting. 4, arm type garbage truck configuration hydraulic cylinder of 1680 mm / Bore 125 mm; arm stroke as follows: empty flat extension 3740 millimeters, supporting the work of the state from the vertical of up to 3890 millimeters, multi-way valve are Sichuan Changjiang Hydraulic Component Factory production, quality, reliable, excellent performance, three bags of service, life-long maintenance. Installation of the balance valve, can effectively improve vehicle efficiency. Uses: mainly applicable to urban waste collection, transfer, convenient and practical, with simple structure, flexible operation, reliable performance, transfer efficiency (more than a garbage truck can be equipped with bucket) and so on. |
||
Hubei Haotian Special Automobile Co., Ltd is specialized in manufacture and marketing of different special automobiles. We are a group management company, and established the wholesome system of manufacture and marketing by the way of joint venture, holding, participation to integrate the resources of the industry. We are successively in the way of joint venture, holding, participation with Hubei Haotian Special Automobile Co., Ltd, Hubei Lutong Special Automobile Co., Ltd, Haotian in Hongkong Special Automobile Co., Ltd. In order to Expand the overseas market, we established the overseas sales and service channel to engage in the trade and investment of overseas sales channel.
The company employ over 1,000 staffs, have a strong technology R&D team and owns plasma cutting machines, plasma screwing machines, large-scale computerized numerical control plate bending machine, automatically welding machines, goliath carling welding machine, cylinder automatic welding machine, cylinder welding special tooling machine, drum equipment ,blade forming mould and so on, more than 300 advanced production equipments .Main products are: road wrecker truck, concrete mixer truck, oil tanker truck, chemical liquid delivery truck, bulk powder delivery truck, crane truck, aerial operation truck, rescue truck ,emergency fire truck, fire sprinkler truck, semi-trailer, sanitation garbage truck, water truck, etc. In order to meet the requirements from different industries, we have been developed the pressure vessel, aluminium tanker, high technology sanitation truck and small construction machinery.
