Home > Products > New Products > multi process cnc router XK45MT-3B
multi process cnc router XK45MT-3B
- 100 Set / Sets per Month
- Qingdao
Product Details
Condition: | New | CNC or Not: | CNC | Place of Origin: | Shandong, China |
Brand Name: | hawk | Model Number: | XK45MT-3B |
Packaging Details
venner case
Product Description
Specifications
multi process cnc router XK45MT-3B1.imported square guide rail
2.stepper motor
3.NCstudio system
4.vaccum table
multi process cnc router XK45MT-3B
Application industry:
XK45MT-3B add cylinders on the basis of three-spindle in one axis, which make the machine can working three different router for three kinds of patterning on the same material, a function of better, more efficient, more convenient for the users. Professional Services in the production of woodworking, cabinets and office furniture such as plate, for flat engraving.
Features:
1.the distance between heads can be adjusted according to the working pieces being processed
2. the spindles can work alternately and shift rapidly, grealy increasing the efficiency and saving the cost, suitable for the working condition of 2-4 tools.
3. Original Ncstudio system, easy to learn and convenient to operate; imported Taiwan linear guide rail, German ball screw and big torque stepper motor, ensure an excellent performance and precise working
4. Rotary attachment is optional, which enable the machine to engrave on column work pieces like table.
5. Especially firm structure and special design on details make the machine to achieve the best performance results
6. Widely application
Furniture industry:
solid wood furniture, wooden door, cabinet,
Wooden products processing: wooden Speakers, wooden Clock, wardrobe, Sports Equipment
Musical instrument: 3D surface engraving and shape cutting.
Artwork making: photo frame, jewelry box
Electronic industry: circuit board, insulation material, LED display screen
Parameters:
Description | |
X,Y,Z working area | 1300*2500*200mm(51.2*98.4*7.9inch) |
X,Y,Z System Resolution | ±0.025mm |
X,Y,Z Reposition accuracy | ±0.05mm |
Table surface | vacuum table |
Lathe bed | Steel-welding structure |
E X,Y transmission | High accuracy gear rack |
Z transmission | Imported ball screw |
Max travel speed | 35000m/min |
Max working speed | 20000m/min |
Spindle power motor | 4.5kw (3kw, 6kw for option) |
Spindle speed | 18000r/min |
Driver system | Stepper motor |
Working voltage | 380V/50-60hz |
Command language | G code |
Operation system | Ncstudio |
Interface | USB2.0 |
Collect | 3.175-12.5 |
Software | Type3, Wentai, ArtCAM |
Company Profile
Jinan creat star cnc router co.,ltd is a professional manufacturer specializing in the R&D,marketing and sales of cnc machines.Our products are widely applied in the wood engraving,mould making and drilling and non-metal engraving fields.
Our company covers an area of 2,000 m2 with 15 assembling lines,and has more than 30 experienced workers,well trained R&D and after-sales staffs.Each year,1000 sets of cnc machines and excellent service are provided for different demands.
our HAWK brand cnc machines are of CE certificate and have been exported to many countries in the world markets,besides, convenient distribution channels have been established in India, Ghana, Saudi Arabia,different customers from diverse industries have found our machines to be reliable and indispensable to their company.
Different cnc products can be provided according to the market demands,one is for the wood working,multiple functions,such as engraving,drilling ,cutting and slotting,can be well done on wood,MDF,aluminum,acrylic and marble;the second is for sign making,it can engrave and cut on acrylic,steel,plastic marble etc;the third is for mould making,it can engrave and drill on aluminum,metal,plastic for mould making,also gluing and engraving in the Expendable casting proces(ECP) can be well done;Besides,our brand laser machine can engrave and cut non-metal materials such as leather ,glass,acrylic and plastic.
Reliable distributors are urgently wanted in the world markets,and we look forward to establishing a long term businese relationship for mutual benefits.
