Mini Cnc Kit XK3030

Name: Mini Cnc Kit XK3030
Brand: hawk
SKU: 105910137
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

CNC or Not:

CNC

Place of Origin:

Shandong, China

Jinan Creat Star CNC Machinery Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not CNC

Place of Origin Shandong, China

Brand Name hawk

Model Number XK3030

Specifications

mini cnc kit XK3030
1.0.8kw water spindle or 1.2kw air cool spindle
2.stepper motor
3.CE certificate

mini cnc kit XK3030

Proper Features

1. Lathe bed is cast wholly and firmly with aluminum alloy and will not deform....

2. Desktop, small, easy to move and use, smart working job with high precision.

3. High speed driver stepper motor could enhance work efficiency.

4. Dust-proof and water-proof device makes the machine be preventive from dust and water and favorable for maintenance.

5. Humanistic design, the machine can be disassembled, so it is easily transported.

6.Applicablematerial:microlite,naturalgranite,seeingstone,marble,bowlder,bluestone,stone,glass, aluminum, iron, plastic and wood etc.

7. Applicable industry: mould and label signage making stone &metal industry.

Specifications:

Machine body	Whole cast by aluminum
working dimensions(X x Y x Z)	300 x 300 x 80mm
Max. Feeding height	120mm or more
Cutting thickness of material	<20mm
Driver type	Stepper motor
Blade diameter	3.175mm,4mm,6mm (optional)
Control system	PC-control(NCSTUDIO) or DSP off-line control(USB)
Running circumstance temperature	0 - 45
Relative humidity	30% - 75%
Spindle Motor	800w water-cooled/ 1.2kw air-cooled spindle motor
Drive mechanism	Germany imported ball screw
Resolution	0.01mm
Max motion Speed	4,200mm/min
Max engraving speed	4,000mm/min
Rotating Speed of Spindle	0~2,4000rpm
Dictate Format	G code
Operating voltage	AC110V/220V 50Hz/60Hz
