wood moulding machine XK1325ATC-0808

veneer case

Specifications

wood moulding machine XK1325ATC-0808
1.Italy HSD spindle
2.japan servo drive system
3.taiwan sytec or LNC control system

wood moulding machine XK1325ATC-0808

Using industry:
Create  Star XK1325ATC-0808 Gantry-type CNC machining center is designed for the customers for a high standard, high demand, high degree of automation. Suitable for large-volume, all-weather processing of non-ferrous, metal plate.
Furniture and Decoration: A large area flat plate engraving, wood, panel furniture carving, wood art murals, wood door, cabinet door sculpture.
Wood Product In dusty: Sewing machine table, electrical counter face, sports equipment
Musical Instrument Industry: Three-dimensional surface can be carved musical instruments, shape cutting.
Model Features
1. Structural stability: Industry into the production model, heavy-duty full steel frame structure,welding,tempering efficient vector processing, solid non-deformed.
2. Good Parts: Taiwan LNC system, Italy HSD spindle motor. And the spindle bearings for high-precision ceramic bearings, low noise, long life.
Adopted from, Taiwan Hiwin 30 linear rail, ball screw from Germany, bearing force, under the knife and accurate. To adopt Japanese Yaskawa servo drive system, torque and has a perfect security system.
3. Modular structure design: Select and add a variety of machining spindle configuration, can be sculpture, engraving, milling work.
4. A simple and secure mode of operation, advanced document pre-processing to ensure the speed and accuracy of operation
5. Automatic tool changing system, knife storage capacity 8 (Optional)
6. High adhesion, vacuum suction device, the displacement of up to 230 cubic meters / hour
7.  Compatible: Open software interface, compatible with type3/arteam/castmate / Wentai a variety of CAD / CAM design software generate the processing code, to ensure the design of barrier-free

Technical parameters

Table  Size	1350*3100mm
X.Y.X axis working area:	1300*2500*200mm
Reposition accuracy:	±0.02mm
Max material height:	300mm
Spindle Power	8KW
Spindle Speed:	18000rpm/Min
Max-speed:	60000mm/Min
Max-cutting speed:	35000mm/Min
System Resolution	±0.002mm
Working voltage	AC380V/50HZ-60HZ   3-phase
Command Code	HPGL/G Code
Controls	LNC510i system/Taiwan
Drive motors	Servo
