Home > Products > Laser Welding Machine/ Laser Welder > Stainless Steel Pipe Welding Machine With High Efficient and Accurate Welding

Stainless Steel Pipe Welding Machine With High Efficient and Accurate Welding

FOB Price

US$ 5,000 - 7,500 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Guangdong, China
Brand Name	superwave laser	Model Number	SW-SW150/200, SW-SW100/150/200
Single Pulse Energy	80/100J	Pulse Width	0.1-20ms
Wavelength	1064nm	Focal Spot Diameter	0.1-2.0mm
Max. Output Power	150/200W	Dimensions	900X450X1100mm
Usage	stainless steel pipe welding	Power(W)	80W/100W/150W/200W
Certification	CE, ISO	Warranty	1year
After-sales Service Provided	Engineers available to service machinery overseas

stainless steel pipe welding machine with High efficient and accurate welding

Product Description

Data-sheet

Model	SW-SW100	SW-SW150	SW-SW200
Type	Bench-top Internal cooling	Workstation Internal cooling	Workstation Internal cooling
Application	K-Gold; Pure Gold;PT;925,950,990 Silver, Diamond Mosaic
Special technology	Cool beam, smallest beam ,sweet beam (no drilling hole on jewellery,no damaged any gem stone or diamond)
Laser medium	Nd:YAG	Nd:YAG	Nd:YAG
Wavelength	1064nm	1064nm	1064nm
Max.output power	100W	150W	200W
Max.pulse energy	80J	100J	120J
Peak power	4KW	6KW	7KW
Pulse duration	0.1-15ms	0.1-20ms	0.1-20ms
Pulse frequency	1-10Hz	1-30Hz	1-50Hz
Focal diameter	0.1-2.0mm	0.1-2.0mm	0.1-2.0mm
Cooling system	Internal cooling system	Internal cooling system	Internal cooling system
Vision system	Stereo microscope 10X	Stereo microscope 10X	Stereo microscope 10X
Program memory	100set	100set	100set
Power supply	AC220V/1Ph/50Hz	AC220V/1Ph/50Hz	AC220V/1Ph/50Hz
Net weight	70kg	120kg	130kg
Delivery times	10Days	10Days	10Days
Warranty terms	1year	1year	1year

Machine and Sample

Application

Packaging & Shipping
