Energy Saving High-tech Iron Welding Machine

Name: Energy Saving High-tech Iron Welding Machine
Brand: superwave laser
SKU: 105880655
Availability: InStock

US$ 5,000 - 7,500 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Guangdong, China

Brand Name:

superwave laser

Shenzhen Superwave Laser Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Guangdong, China

Brand Name superwave laser

Model Number SW-SW150/200, SW-SW100/150/200

Single Pulse Energy 80/100J

Pulse Width 0.1-20ms

Wavelength 1064nm

Focal Spot Diameter 0.1-2.0mm

Max. Output Power 150/200W

Dimensions 900X450X1100mm

Usage jewelry laser welder

Power(W) 80W/100W/150W/200W

Certification CE, ISO

Warranty 1year

After-sales Service Provided Engineers available to service machinery overseas

energy saving high-tech iron welding machine with Germany laser source

Product Description

Data-sheet

Model	SW-SW100	SW-SW150	SW-SW200
Type	Bench-top Internal cooling	Workstation Internal cooling	Workstation Internal cooling
Application	K-Gold; Pure Gold;PT;925,950,990 Silver, Diamond Mosaic
Special technology	Cool beam, smallest beam ,sweet beam (no drilling hole on jewellery,no damaged any gem stone or diamond)
Laser medium	Nd:YAG	Nd:YAG	Nd:YAG
Wavelength	1064nm	1064nm	1064nm
Max.output power	100W	150W	200W
Max.pulse energy	80J	100J	120J
Peak power	4KW	6KW	7KW
Pulse duration	0.1-15ms	0.1-20ms	0.1-20ms
Pulse frequency	1-10Hz	1-30Hz	1-50Hz
Focal diameter	0.1-2.0mm	0.1-2.0mm	0.1-2.0mm
Cooling system	Internal cooling system	Internal cooling system	Internal cooling system
Vision system	Stereo microscope 10X	Stereo microscope 10X	Stereo microscope 10X
Program memory	100set	100set	100set
Power supply	AC220V/1Ph/50Hz	AC220V/1Ph/50Hz	AC220V/1Ph/50Hz
Net weight	70kg	120kg	130kg
Delivery times	10Days	10Days	10Days
Warranty terms	1year	1year	1year
