Specifications
Ice plant:1.Making flake ice is from 500kg to 2500kg/24h ,
2.Slice ice thickness is :1.5-2.0mm
3.Air cooled .
I. Flake ice application fields:
Aquatic products processing .
Meat processing .
Fishery industry .
Vegetable preservation .
Supermarket or other commercial usage .
Cold storage project .
Temperature reduction project .
Compared with Ice tube Flake ice have a bigger contact area .It has the best refrigeration effect of all kinds and forms of Ice .The surface area for every ton of Ice flake can be as large as 700m2
II. Technology parameter of Ice plant:
Model | Cooling Capacity | Production /24hrs | Evaporator temperature °C | Total installation power | Cooling type | Net weight |
XIFA-050S | 2801kcal/h | 500kg | -20 | 2.7kw | Air cooled | 220kg |
XIFA-060S | 3870kcal/hr | 600kg | -20 | 3.0kw | Air cooled | 225kg |
XIFA-075S | 5160kcal/h | 750kg | -20 | 3.5kw | Air cooled | 230kg |
XIFA-10S | 6450kcal/h | 1000kg | -20 | 4.5kw | Air cooled | 252kg |
XIFA-16S | 9675kcal/h | 1600kg | -22 | 8.3kw | Air cooled | 274kg |
XIFA-20S | 12900kcal/h | 2000kg | -22 | 10.7kw | Air cooled | 397kg |
XIFA-25S | 16125kcal/h | 2500kg | -22 | 10.7kw | Air cooled | 411kg |
1.Voltage: 3Ph-380V-50HZ and 3PH-220V-60HZ 2.Refrigerant :R507 |
| |||||
III.Certificates of Ice plant :
