Help CenterInjection Machine Using Small Air Chiller
Related Products
-
Injecton Machine Using Small Air CoolerUS$ 1,180 - 19,800MOQ: 1 Set -
Industrial Screw Style Air Chiller Price ListUS$ 15,800 - 79,000MOQ: 1 Set
-
Small Air Chiller for SaleUS$ 1,100 - 1,980MOQ: 1 Set
-
25HP Air Cooled ChillerUS$ 8,900 - 9,500MOQ: 1 Set
-
16HP Air Cooled Chiller PriceUS$ 5,750 - 6,800MOQ: 1 Set
Specifications
Air chiller :1.Best quality and Simple operate.
2.Cooling capacity is over 30% more than ordinary.
3.Small size
Air chiller
I. Instruction of Air chiller:
XHC Air chiller is widely used for hotels, hospitals, theaters, sports, entertainment center, commercial buildings, office buildings, working conditions at places such as development and design company central air conditioning products, it can installed on the roof or outside the hospital, without special room and cooling tower.
1.Energy efficient,
2.Modular, free combination, easy installation, stable performance,
3, Intelligent control, easy operation, safety
4.Low noise, stable operation and 5, have the ability to network communication
Features:
- Air chiller is an ideal choice for places with much dusts and filth.
- Air chiller is suitable for area with low-quality water, and it can save the cooling tower and auxiliary devices.
- Its large-capacity condenser operate well in even very hot seasons
Condensing Type: air cooled
Application: Injection Molding, Food Industry, Chemical Industry, Central Air-Conditioner
II. Technology parameter of Air chiller :
Models |
Cooling |
Input |
Compressor |
Evaporator |
Condenser |
The machine |
Capacity |
Power |
Flow water |
Cooling air |
size |
||
The models below include 1 Compressor | ||||||
XCA-02S |
4988kcal/hr |
2.5kw |
1.9kw |
1.3m3/h |
2270m3/h |
0.8*0.6*0.85m |
XCA-03S |
8428kcal/hr |
3.4kw |
2.9kw |
1.8m3/h |
3400m3/h |
0.95*0.68*1.0m |
XCA-05S |
13,932kcal/hr |
5.7kw |
4.8kw |
2.6m3/h |
4550m3/h |
1.28*0.68*1.2m |
XCA-08S |
21,156kcal/hr |
8.5kw |
7.5kw |
4.2m3/h |
6800m3/h |
1.24*0.73*1.38m |
XCA-10S |
27,090kcal/hr |
11.4kw |
9.8kw |
5.5m3/h |
9600m3/h |
1.5*0.8*1.32m |
XCA-12S |
31,304kcal/hr |
13.3kw |
11.8kw |
6.6m3/h |
9600m3/h |
1.5*0.8*1.35m |
The models below include 2 Compressors | ||||||
XCA-16D |
41,796kcal/hr |
18.1kw |
15.2kw |
7.8m3/h |
1 3200m3/h |
1.58*0.95*1.46m |
XCA-20D |
53,750kcal/hr |
22.8kw |
19.8kw |
11.2m3/h |
19800m3/h |
2.5*1.0*1.5m |
XCA-25D |
62,264kcal/hr |
26.9kw |
23.8kw |
13.4m3/h |
26000m3/h |
2.5*1.0*1.58m |
XCA-30D |
83,420kcal/hr |
36.5kw |
30.6kw |
16.6m3/h |
265000m3/h |
2.65*1.0*1.58m |
XCA-40D |
107,500kcal/hr |
45.8kw |
39.5kw |
21.2m3/h |
39800m3/h |
2.8*1.15*1.68m |
XCA-50D |
124,700kcal/hr |
53.9kw |
47.2kw |
26.5m3/h |
52000m3/h |
2.8*1.9*1.75m |
Note : | ||||||
1.The details above is based on the following parameter :Evaporator temperature:10°C, Condensing temperature:54.4°C | ||||||
2.Main Voltage :3P-380V/50HZ ,3P-220V-50HZ/60HZ | ||||||
3.Refrigerant :R22 | ||||||
III.Main parts of Air chiller
Item |
Model |
Brand |
Remark |
|
Compressor |
|
COPELAND |
USA |
|
Computer control |
|
XHC |
XHC PATENT |
|
Refrigerant |
R22 or R404a |
DUPON |
USA |
|
|
Electrical Accessories |
|
ZHENGTAI |
China |
|
Condenser |
|
XHC |
XHC PATENT |
|
Evaporator |
|
XHC |
XHC PATENT |
|
Pressure Gauge |
|
GARHOPE |
Sino-American joint venture |
|
Solenoid |
|
FENSHEN |
XHC PATENT |
|
Expansion Valve |
|
SAGINOMIYA |
Japan |
|
Filter |
|
SANRONG |
XHC PATENT |
|
Economizer |
|
XHC |
XHC |
|
Copper Tube |
|
HONGTAI |
Qingdao,China |
|
Steel |
|
BAOSTEEL |
Shanghai,China |
|
Pressure Controller |
|
FENSHEN |
XHC PATENT |
|
Stop valve |
|
FENSHEN |
XHC PATENT |
|
