Specifications
Trapezoid Jigger1 High capacity
2 High concentration ratio and high recovery
3 Adjustable speed easily
Sievo Trapezoid Jigger / Trapezoid Jigger on Sale / New Style Trapezoid Jigger
Trapezoid Jigger Descriptions
Our Trapezoid Jigger is a new type of energy saving and high efficient gravity separation equipment and developed based on the traditional Sine Wave Jig. The difference between Trapezoid Jigger and Sine Wave Jig is that the pulsation curve for jigging is saw-tooth wave shape, with speedy upward flow and slow downward flow. Bed layer is elevated integrally and slowly dropped with a long effective loose time, allowing significant increase of handling capacity for unit screen surface, decrease of lower limit of grain size recovery and large save of make-up water for under size fraction.
Trapezoid jigger is the sine-wave side-moving jigger with double rows of eight chambers. It's working section become wider along the ore pulp flowing direction. The stoke and stroke times of each paralleing chamber can be adjusted independently to form different jigging frequency. It has the character of big capacity, big feeding rang and high recovery rate and strong applicability.
The trapezoid jipper is widely used in the water benefication processing of jigger for alluvial god, alluvial tin, tungsten, tatalum, mercury, antimony, hematite, limonite,pyrite, etc.
Trapezoid Jigger Advantages and Characteristics
(1) High capacity
(2) High concentration ratio and high recovery
(3) Easy to install, operate and maintain
(4) Saving water 30-40% than ordinary jig
(5) The pulsation speed very easily adjusted by regulator
(6) Can achieve a good result in processing
Trapezoid Jigger Main Technical Parameters
| model | section style | chamber No. | feeding size(mm) | stroke(r/min) | stroke times(r/min) | capacity(t/h) | power(kw) |
| 2LTC6109/8T | trapezoid | 8 | 0-8 | 0-50 | 0-300 | 20-40 | 1.5*4 |
| 2LTC-366/8T | trapezoid | 8 | 0-8 | 0-50 | 0-300 | 3-6 | 1.1*21 |
Why choose our company machine
We are manufacturer in Shanghai, China. Shanghai is known as the “Pearl of China”. It serves as the largest base of Chinese industrial technology, and the busiest container port in the world. The competition in this city is severe, only companies with ending technology, stable workforce, and effective cost management could survive. With 20 years of efforts and innovation, our machine is now a leading brand in China.
Affordable, high-quality machines. Our highly competitive price relies upon our ability to minimize our costs, of which our competitors don’t.
1. We are factory(NOT Dealer)
2. We own our factory & Land (NOT Rent)
3. Staff reside in factory(Stable Workforce)
Producing high-quality and reliable machines is always our first priority, because we know that our success depends entirely on the satisfaction of our customers.
We never give-up quality to save cost, instead we built our machines.
Training & service.
Training is FREE to every customer. Whenever you need us, for installation, maintenance, or proper use of our company machines, we will be right there for you. In addition, we provide one-year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.
