High Production and Low Consumption Mining Mixing Drum
Mining Mixing Drum Introduction
Mining Mixing Drum is also called mining stirred tank, mineral mixer. It is the necessary equipment that dynamic V-belt of motor drive rotating impeller will be mixed full of drugs and pulp evenly, increasing reaction time.
The mine-used mixing drum applies to all kinds of metal mine which mainly be used as mixing before flotation. It blends the medicine and pulp, and also it can mix other non metallic minerals. It used the density of less than 30% and frozen composition of less than 1mm, and the formation is flat-bottom barrel radiation with circle cross collar of mechanical mixing.
Mining Mixing Drum Application
Mixing drum is of the necessary equipment that dynamic V-belt of motor drive rotating impeller will be mixed full of drugs and pulp evenly, increasing reaction time, strengthen the role of pharmaceutical drug reactions quality, the machine applies to election mining, the chemical industry also can be used as mixing ingredients.
Mining Mixing Drum Feature
The mine-used mixing drum applies to all kinds of metal mine which mainly be used as mixing before flotation. It blends the medicine and pulp, and also it can mix other non metallic minerals.
It used the density of less than 30% and frozen composition of less than 1mm, and the formation is flat-bottom barrel radiation with circle cross collar of mechanical mixing.
Working Principle of Mining Mixing Drum:
Stirs the barrel to use in front of the flotation process work the pulp stirring, causes the pulp and medicament intensive mixing, and creates condition for Mine selection working.
Technical Parameter of Mining Mixing Drum
Type |
Tank Diameter (mm) |
Tank Height (mm) |
Active Volume (m3) |
Speed (r/min) |
Impeller Diameter (mm) |
Weight (t) |
Motor |
Size (mm) |
|
Type |
Power |
||||||||
XB-500 |
500 |
500 |
0.098 |
600 |
200 |
0.15 |
Y90S-6 |
1.1kw |
600×566×954 |
XB-750 |
750 |
750 |
0.33 |
530 |
255 |
0.6 |
Y90L-4 |
1.5kw |
1131×880×1241 |
XB-1000 |
1000 |
1000 |
0.58 |
530 |
255 |
0.99 |
Y90L-4 |
1.5kw |
1131×1130×1492 |
XB-1200 |
1200 |
1200 |
1.4 |
300 |
400 |
1.05 |
Y132S-6 |
3kw |
1500×1480×1800 |
XB-1500 |
1500 |
1500 |
2.2 |
320 |
400 |
1.2 |
Y132S-6 |
3kw |
1750×1640×2190 |
XB-2000 |
2000 |
2000 |
5.46 |
230 |
550 |
1.6 |
Y132M2-6 |
5.5kw |
2380×2162×2850 |
XB-2500 |
2500 |
2500 |
11.2 |
230 |
650 |
3.44 |
Y160L-6 |
11kw |
3036×2716×3543 |
XB-3000 |
3000 |
3000 |
19.1 |
210 |
700 |
4.61 |
Y225S-8 |
18.5kw |
3604×3216×4250 |
XB-3500 |
3500 |
3500 |
30 |
230 |
850 |
7.28 |
Y225M-8 |
22kw |
3940×3766×5386 |
