600W 5blades 2.5m/s wind power generator/windmill max 680w new type

Model

Z-600W

Name

City Swallow

Rated power

600W

Rated DC voltage

DC 24V

Rated current

25A

Rated speed

640r/m

Max power

680W

Number of blade

5pcs

Starting wind speed

2.5m/s

Cut-in wind speed

3m/s

Cut-out wind speed

15m/s

Security wind speed

45m/s

Rated wind speed

12m/s

Engine

Three-phase permanent magnel generator

Rotor diameter

1850mm

Blade material

Carbon fiber reinforced plastics

Output line anti-winding device

Over all three-phase commutator

Over-speed wind protection

Tip stall protection + turned protection + Electromagnetic brake

Life span

15 years

Equipment surface protection

Aluminum oxide + plastic coating

Working temperature

-45°C-70°C

N.W.

21.3kg

Packing material

Carton box and foam material

packing dimension

970*460*230mm

G.W.
