Wholesales 600w wind turbine High efficiency power generator12v/24v DC+Wind charger regulator controller
- 5000 Set / Sets per Month
- ShenZhen
- Credit Card
- China manufacture Lock sheet Generator QFSN-300-2-20B for Pacitcan TPP material
- Yawing horizontal axis wind generator 25kw
- 2kw Eolica wind generator
- 3KW 360 RPM Permanent Magnet Generator For Wind Turbine Or Hydro Turbine Customized Electric Motor
- 2000W Wind-solar Hybrid Home Wind Power Generation Five-blade portable manufacturers 48v wind generator turbine price
- 300w household small wind generator solar wind energy power generation system micro generator set home use wind turbines price
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Green Elec | Model Number: | Z-600 |
Type: | Wind Power Generator |
Product Description
Specifications
low start-up wind speedHigh efficiency 600W
2 years guarantee time
CE Rohs Certificate
Large power, small volume wind turbine
Low start wind speed wind generator
High efficiency of anti-wind ability
High cost-effective wind generator system
Home use Household wind energy generator tubine
Product Characteristics:
1. Large power, low volume, low weight, high efficiency
2. Carbon fiber blades, high efficiency of anti-wind ability
3. Blades with the ability of automatically stall protection under strong wind
Product Specification:
Model | Z-400W | Z-600W | ||
Name | City | City | ||
Rated power | 400W | 600W | ||
Rated DC voltage | DC 12V/24V | DC 12v/24v | ||
Rated current | 33A/17A | 50A/25A | ||
Rated speed | 740r/m | 640r/m | ||
Max power | 460W | 680W | ||
Number of blade | 3 pcs | 5 pcs | 5 pcs | |
Starting wind speed | 3m/s | 2.5m/s | 2.5m/s | |
Cut-in wind speed | 3.5m/s | 3m/s | 3m/s | |
Cut-out wind speed | 15m/s | 15m/s | ||
Security wind speed | 45m/s | 45m/s | ||
Rated wind speed | 12m/s | 12m/s | ||
Engine | Three-phase | Three-phase | ||
Rotor diameter | 1450mm | 1850mm | ||
Blade material | Carbon fiber | Carbon fiber | ||
Output line | Over all | Over all | ||
Over-speed wind | Tip stall | Tip stall | ||
Life span | 15 years | 15 years | ||
Equipment surface | Aluminum oxide + | Aluminum oxide + | ||
Working | -40°C-70°C | -45°C-70°C | ||
N.W. | 15kg | 16kg | 19kg | |
packing dimension | 980*480*260mm | 980*480*260mm | ||
G.W. | 20kg | 18kg | 20kg | |
Tower | 5M(60mm zinced iron tube) | 5M(60mmzinced iron tube) | ||
Packing material | Carton box and | Carton box and | ||
Packing dimension | 1580*320*150mm | 1580*320*150mm | ||
Controller | 400w | 600w | ||
Inverter | 500w | 600w |
Relevant products
Wind controller
It can change the wind turbine's current from three-phase AC to Two-phase DC.
Function:
1.Over load protection
2.Over-speed Bracking.
Connection mode
1,Red and black lines connect with battery Positive and negative
2,Three green lines connect with wind generator freely,no color request.
Indicating state
1,When controller Green indicator of battery light is bright,it means the battery is connected successfully
2,When controller Green indicator wind of generator is bright,it means wind generator is connected successfully,the speed of the flashing means the speed of the Wind generator rotation
3,When controller Red indicator is bright,it means the battery is fully charged.the wind generator will breake automatically.
Notice
1,Please make sure the wind generator rated voltage is the same as the battery rated voltage. 2, According to the following sequence connection.Frist,connect with battery(please notice Positive and negative ).then connect with wind generator.
Factory
Wind tunnel
Simulate common wind to see how wind generator how to work
Production workshop
Product certification
