Mini Wind Turbine 50w/100w Horizontal Wind Turbine

Name: Mini Wind Turbine 50w/100w Horizontal Wind Turbine
Brand: Green Elec
SKU: 104683665

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Green Elec

Model Number:

P-100w

Shenzhen Green Electricity Kang Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Green Elec

Model Number P-100w

Type Generator

Electricity Generator Type Wind Power

Output Voltage (V) 12

Specifications

1.low weight, convenient to carry
2.with CE, RoHS and ISO9001:2000 certificates
3.good quality at a favorable price

Model	Z-50W	Z-100W
Name	Hyacinth	Hyacinth
Rated power	50W	100W
Rated DC voltage	DC 12V/24V	DC 12V/24V
Rated current	4.4A/2.2A	8.8A/4.4A
Rated speed	1050r/m	860r/m
Max power	65W	115W
Number of blade	3 pcs	3 pcs
Starting wind speed	3m/s	3m/s
Cut-in wind speed	3.5m/s	3.5m/s
Cut-out wind speed	15m/s	15m/s
Security wind speed	45m/s	45m/s
Rated wind speed	12m/s	12m/s
Engine	Three-phase permanent magnel generator	Three-phase permanent magnel generator
Rotor diameter	830mm	1050mm
Blade material	Carbon fiber reinforced plastics	Carbon fiber reinforced plastics
Output line anti-winding device	Overall three-phase commutator	Overall three-phase commutator
Over-speed wind protection	Tip stall protection + turned protection + Electromagnetic brake	Tip stall protection + turned protection + Electromagnetic brake
Life span	10 years	10 years
Equipment surface protection	Galvanization plastic coating	Galvanization plastic coating
Working temperature	-40°C-70°C	-40°C-70°C
N.W.	2.6kg	2.8kg
Packing material	Carton box and foam material	Carton box and foam material
packing dimension	620260220mm	620260220mm
G.W.	3.2kg	3.5kg
