Small rod mill is known as the grinding medium in the cylinder body is steel bar,rod mill is generally use the wet overflow type and can be widely used as the first level open grinding in artificial sandstone,beneficiation, chemical industry . The product size characteristics of rod mill is related to crushing ,In the grinding process ,it first crush the coarse grain, and then grind the smallerore,reducing the risk of overgrind. When the bar turn up wtih the liner plate, hode the coarse grain and make fine grain pass the gasp, this also is helpful to clip broken the coarse grain, and make coarse grain concentrate on grinding medium place. Therefore, the product of rod milling is uniform.
The motor through the gear reducer and the surrounding low speed synchronous motor drive or by direct transmission through the surrounding large gear to drive the cylinder rotation. Cylinder body with the appropriate grinding media steel bar. Grinding media in the role of centrifugal force and friction, was promoted to a certain height, the state was thrown down or fall off the vent. By grinding the material to mine from the mouth into the cylinder continuous internal movement of the grinding media is shattered, and through the overflow to the mine and the power of continuous product from outside, a process for the next operation.
Small rod mill advantages:
Rod mill grinder has dry and wet two types to choose, user could choose depend on the fact. LanJi company uses the advanced output controllable technology, with the face milling material set the suitable miller, change the traditional surface contact into line contact, make the output granularity evener, high product, widely used in chemical industry, metallurgy, glassed industry, and the high rquirement of the evenness for milling after milling, sand making of building sand in recent years.
Small rod mill technical parameters:
Model |
drum diameter (mm) |
drum length(mm) |
Feed size(mm) |
Discharge size(mm) |
Capacity (t ) |
Power(KW) |
Weight(KG) |
HS-0930 |
900 |
3000 |
6-25 |
0-5 |
3-8 |
22 |
4500 |
HS-1224 |
1200 |
2400 |
6-25 |
0-5 |
5-25 |
45 |
12000 |
HS-1245 |
1200 |
4500 |
6-25 |
0-5 |
6-35 |
55 |
13800 |
HS-1530 |
1500 |
3000 |
6-25 |
0-5 |
7-45 |
90 |
17000 |
HS-1545 |
1500 |
4500 |
6-25 |
0-5 |
3.6-11 |
110 |
21500 |
HS-1557 |
1500 |
5700 |
6-25 |
0-5 |
10-85 |
132 |
24700 |
HS-1860 |
1800 |
6000 |
6-30 |
0-5 |
20-100 |
210 |
34000 |
HS-2136 |
2100 |
3600 |
6-40 |
0-5 |
30-110 |
215 |
45000 |
After our workers' hard work ,the production of the rod mill is finished
we deliver rod mill according to our customer' s demands
