Specifications
fine crushers are new highly effective ones(the third generation system sand maker).it has many specifications for your choice.PXJ 800×400, 800×600, 800×800, 1000×1000, 1200×1000 ,1200×1200,1400×1400,1600×1600,1800×1800 fine crusher in our company is new highly effective fine crusher(the third generation system sand maker). It is made by referring to different models crushes principle of work, according to the information feedback of user, and combining the advantages of different model crushers. Its typical use lies in the adaptation in current artificial machine-made sand making industry. These style crushers are the substitution products of rod milling sand maker, impact sander maker and through sand maker.
feature
The products have some characteristics: the small discharging size, uniform grain, large capacity, long life nammer, small power, and change three broken into two broken, simple technology, simple structure, easy maintenance, the smooth running and so on.
Equipment investment is lower 35% -50% than the same size of the traditional equipment, the output efficiency is higher 35% -50%, the cost of maintenance after long running is lower 35%-50%. These equipment widely used in sand making industry(limestone, river gravel, cobblestone, weathered rock, quartz etc), cement, refractories, metallurgy.
|
Motor diameter × wideth (mm) |
Size of feed opening (mm) |
Maximum Feed size (mm) |
Discharging size (mm) |
Adjustable Width of Discharging Grate gap (mm)
|
output (T/h) |
Motor power (kw) |
|
|
Cement clinker |
limestone |
||||||
Ø800×400 |
400×185 |
<120 |
<5 |
5-20 |
20-30 |
35-45 |
37-45 |
Ø800×600 |
500×250 |
<180 |
<5 |
5-20 |
35-40 |
45-55 |
45-55 |
Ø800×800 |
550×330 |
<180 |
<5 |
5-20 |
35-45 |
55-65 |
45-55 |
Ø1000×1000 |
1000×350 |
<180 |
<5 |
5-20 |
45-55 |
65-75 |
55-75 |
Ø1200×1000 |
1200×400 |
<180 |
<5 |
5-20 |
55-80 |
75-100 |
100-110 |
Ø1200×1200 |
1200×450 |
<180 |
<5 |
5-20 |
75--90 |
90-100 |
100-132 |
Ø1400×1400 |
1500×500 |
<190 |
<5 |
5-20 |
90--130 |
100-150 |
160 |
Ø1600×1600 |
1600×550 |
<190 |
<5 |
5-20 |
170-210 |
190-250 |
250 |
Ø1800×1800 |
1800×800 |
<190 |
<5 |
5-20 |
250-270 |
280-310 |
315 |
