Specifications
Jaw Crusher:1)High jaw crushing ratio
2)Even product granulle
3)Robust construct jaw crusher
4)Perfect performance crusher
Offer a complete set of crusher plant, the capacity of full line can reach from 50t/h to 500t/h. Generally speaking,Crusher plant includes jaw crusher, impact crusher (or cone crusher), vibrating feeder, vibrating screen, belt conveyor, etc. And crusher plant mainly offers materials for railway and high way industries, and construction.
Jaw crusher, stone crusher, crusher
The application of jaw crusher:
Jaw Crusher is ideally suitable for primary and secondary crushing, with low power consumption and easy maintenance. Every feature of these crushers has been carefully designed to provide superior quality and performance .The jaw crusher are widely used for crushing various materials like stone ,granite ,trap rock , coal ,manganese ore ,iron ore ,fuse aluminum ,oxide ,etc .These crushers are recommended by consultants in this field and are used by hundreds of customers all over the world.
Features of jaw crusher:
* The crushing equipment is suitable for crushing maximum ,medium, and minimum stones
* Reasonable structure, reliable working, easy maintenance, convenient and economical operations;
* It possesses big adjustable range and can meet different requirements of customers;
* The crushing compressive strength of the different kinds of materials should not be in excess of 350 Mpa;
* The jaw crusher adopts the design of dent form jaw plate and complex stroke, and the crushing efficiency is high;
* Low noise and less stone dust
Technical parameters of jaw crusher
Type |
Input size |
Max feed size |
Adjusting range |
Capacity |
Rotor speed |
Rotary power |
Weight |
Dimensions (L×W×H) |
PE-400×600 |
400×600 |
340 |
40-90 |
10-40 |
275 |
30 |
7.2 |
1700×1732×1392 |
PE-350×750 |
350×750 |
290 |
30-55 |
20-50 |
300 |
37 |
8.9 |
1900×1806×1808 |
PE-500×750 |
500×750 |
425 |
50-100 |
35--70 |
275 |
55 |
11.4 |
2050×1860×2145 |
PE-600×900 |
600×900 |
500 |
80-200 |
40-120 |
255 |
75 |
17.6 |
2792×2168×2250 |
PE-750×1060 |
750×1060 |
630 |
80-200 |
80-160 |
250 |
90 |
30.6 |
4180×2560×3070 |
PE-900×1200 |
900×1200 |
750 |
100-200 |
110-200 |
250 |
110 |
50 |
5200×2900×3500 |
PE-1000×1200 |
1000×1200 |
850 |
195-265 |
315-500 |
200 |
110 |
55 |
3480×2876×3330 |
PE-1200×1500 |
1200×1500 |
1020 |
150-300 |
400-800 |
180 |
160 |
100 |
4200×3300×3500 |
PEX-150×750 |
150×750 |
125 |
10-40 |
8-25 |
300 |
15 |
3.8 |
1220×1480×1180 |
PEX-250×1000 |
250×1000 |
210 |
15-60 |
16-52 |
300 |
37 |
7.4 |
1580×1992×1390 |
PEX-250×1200 |
250×1200 |
210 |
15-60 |
20-61 |
300 |
37 |
8.7 |
1730×2192×1380 |
PEX-300×1300 |
300×1300 |
250 |
20-90 |
16-105 |
300 |
55 |
11.6 |
1930×2400×1747 |
Note: This specification is just for reference, any changes are subject to the products.
For further details, please feel free to contact
Tel: 86-371-67511065 Mobie:86-13523521812
