Specifications
Quartz Crusher35 years mining machine manufacturer
Excellent quality
widely used to crushing quartz, marblr, gravel
Quartz Crusher Application:
This series of crusher is promoted on the basis of the same kind of crusher. It adopts technology of home and
aboard, optimizes the main technical data. As a new type crusher of fine crushing and coarse milling , it is
suitable for medium cement industry and widely used to improve old cement factory and establish new
cement factory, also can be used to crush iron ore, sand rock, clinker, gypsum, block coal and other medium-hard material. It has features like simple structure, large crushing ratio, high capacity, even particles,
convenient maintenance, low production cost and so on.
Quartz Crusher:
Vertical combination crusher is a new type and high effective fine crusher researched by Jinma mining Machinery Co.,Ltd. Which collects advantages of boty Gardner Crusher and Impact Crusher. It integrates shock, impact,centrifugation, strike, cutting and milling together. It is widely applied for fine crushing in building materials, chemical industry, mining and metallurgy.
Vertical combination crusher technical parameters:
Specification |
Diameter (mm) |
Capacity (t/h) |
Feed size(mm) |
Discharge size (mm) |
Main shaft speed (r/min) |
motor |
Outside measurement (lengh×width×height) (mm) |
weight (t) |
|
|
Specificity |
Power (kw) |
||||||||
PCL750 |
750 |
12-15 |
≤80 |
0-5 |
720 |
Y200L-4 |
30 |
2000×1100×1375 |
3.1 |
PCL1000 |
1000 |
25-30 |
≤90 |
0-6 |
500 |
Y280M-6 |
55 |
2690×1500×1600 |
4.6 |
PCL1250 |
1250 |
35-40 |
≤100 |
0-7 |
420 |
Y315M1-8 |
75 |
3270×1600×1900 |
6 |
PCL1500 |
1500 |
55-70 |
≤120 |
0-8 |
400 |
Y315M3-8 |
110 |
3400×2000×2300 |
9.5 |
PCL1750 |
1750 |
80-100 |
≤150 |
0-9 |
380 |
Y315M3-8 |
160 |
3710×2360×2390 |
15 |
PCL2000 |
2000 |
110-130 |
≤180 |
0-10 |
370 |
Y315M3-8 |
185 |
4100×2660×2620 |
20 |
Vertical Combination Crusher
For further details, please feel free to contact
Tracy (International Director)
Zhengzhou Jinma Mining Machinery Co., Ltd.
Tel: 86-371-67511065 Fax: 0086-371-67512579
Mobile:86-150-382-13376
