Specifications
Glass Crusher35 years experiemce
ISO9001& SGS
Excellent quality Combination
PCL Series Glass Crusher
This crusher has big breaking ratio, discharging size is adjustable , don't suffer from the wear of plate hammer and the plate, it is not easy to plug when crushed high moisture large mud containing materials; Using elastic and regulatory structure, the material which can not broken ,they will be automatically discharged, it cant make the damage to equipment; the bearing is horizontal and with long life, it can break high temperature materials (such as cement clinker); unique rotor structure, when break materials, the rotor body is virtually non-wear; the behind Cavity set-up screw rod or hydraulic open structure, do not need main equipment you can easily replace the easy wearing parts.
PCL Series Combination Crusher Working principle
Materials fall into the high-speed rotation impeller from the above of machine, under the action of high-speed centrifugal force, have high-speed impact with another umbrella form materials which flow around the impeller, after they attack each other, then discharged from the bottom, it forms close-circuit and with many times circulation, it can achieve the required product size by screening equipment controlling.
|
Specification |
Diameter (mm) |
Capacity (t/h) |
Feed size(mm) |
Discharge size (mm) |
Main shaft speed (r/min) |
motor |
Outside measurement (lengh×width×height) (mm) |
weight (t) |
|
|
Specificity |
Power (kw) |
||||||||
PCL750 |
750 |
12-15 |
≤80 |
0-5 |
720 |
Y200L-4 |
30 |
2000×1100×1375 |
3.1 |
PCL1000 |
1000 |
25-30 |
≤90 |
0-6 |
500 |
Y280M-6 |
55 |
2690×1500×1600 |
4.6 |
PCL1250 |
1250 |
35-40 |
≤100 |
0-7 |
420 |
Y315M1-8 |
75 |
3270×1600×1900 |
6 |
PCL1500 |
1500 |
55-70 |
≤120 |
0-8 |
400 |
Y315M3-8 |
110 |
3400×2000×2300 |
9.5 |
PCL1750 |
1750 |
80-100 |
≤150 |
0-9 |
380 |
Y315M3-8 |
160 |
3710×2360×2390 |
15 |
PCL2000 |
2000 |
110-130 |
≤180 |
0-10 |
370 |
Y315M3-8 |
185 |
4100×2660×2620 |
20 |
PCL Series Combination Crusher
