Home > Products > Diesel Engine > Engine 186F/8hp
Engine 186F/8hp
Negotiable
/ Set
10 Sets(Min.Order)
- 10000 Set / Sets per Month
- T/T
You May Like
-
2015 NEW DESIGN 3-10hp Diesel engine both hand start and key start HOT SALE
-
8HP Diesel engine air cooled KA186F Best price and service CE ISO BV approved
-
Diesel Engine /8hp small diesel engine
-
8 hp single cylinder diesel engines
-
easy start diesel engine/7.6HP engine diesel
-
7.6-8.4HP diesel engine/motors
Product Details
| Condition | New | Fuel | Diesel | |
| Stroke | 4 Stroke | Cylinder | Single Cylinder | |
| Cold Style | Other, Air-cooled | Start | Other, recoil starter | |
| Place of Origin | Jiangsu, China | Brand Name | KAIAO | |
| Model Number | KA186F |
Product Description
Engine 186F/8hp
1.CE&ISO9001 approved powerful output
2.Beautiful appearance, best quality, reasonable price
3.Low noise & convenient maintenance
4.Light and handy in structure
5.Simple installation & stable operation
6.Fuel-saving,quick starting
7.Wide application, such as generating sets & water pump
| Model | KA186F |
| Rated output(HP/rpm) | 7.6HP/3000, 8.4HP/3600 |
| Rated output(KW/rpm) | 5.7KW/3000, 6.3KW/3600 |
| Engine type | Single-cylinder, vertical, four-stroke, air-cooled, direct injection |
| Cylinder Diameter*stroke(mm) | 86X70 |
| Piston displacement (L) | 0.406 |
| Compression ratio | 19 |
| Max. no-load speed(r/min) | 108% of Rated rotary speed |
| Min. no-load speed(r/min) | 1300 |
| Lubrication system | Pressure splash complex Type |
| Engine starting system | Recoil starter or Electric starter |
| Output terminal rotation | AnticlockWise |
| Fuel oil model | Summer:0#, Winter:-10# |
| Fuel tank capacity (L) | 5.5 |
| Fuel consumption rate(g/kW.h) | 275.1/3000 281.5/3600 |
| Oil consumption rate(g/kW.h) | 4.08 |
| Oil grade | CD grade or SAE10W-30,15W-40 |
| Valve clearance(cold state) mm | 0.10-0.15 |
| Lube oil capacity (L) | 1.65 |
| Starting motor (V,kW) | 12V 0.8kW |
| Charging generator(V,A) | 12V 3A |
| Battery capacity(V,AH) | Above 12V-36AH |
| Dimension (L*W*H)(mm) | 522*522*578 |
| Net weight(kg) | 47 |
