Easy Start Diesel Engine/7.6HP Engine Diesel

Name: Easy Start Diesel Engine/7.6HP Engine Diesel
Brand: KAIAO
SKU: 104339965
Availability: InStock

US$ 200 - 250 MOQ: 5 Pieces

Key Specifications

Usage:

Boat

Fuel:

Diesel

Stroke:

4 Stroke

Wuxi Kaiao Power Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Usage Boat

Fuel Diesel

Stroke 4 Stroke

Cylinder Single Cylinder

Cold Style Other, Air-cooled

Start Electric Start

Place of Origin Jiangsu, China

Brand Name KAIAO

Model Number KA186F


Model	KA186FE
Type	Single-cylinder,vertical,4-stroke air-cooled diesel engine
Combustion system	Direct lnjection
Bore X Stroke(mm)	86x70
Displacement(cc)	406
Speed(rpm)	3000	3600
Max.output(kw)	6	6.3
Rated output(kw)	5.7	6
Max.no-load speed(r/min)	108%
Min.no-load speed(r/min)	1300
Fule	0# or -10#light diesel oil
Fule oil tank volume(L)	5.5
Lubricatiom oil volume(L)	1.65
Fule oil consumption rate(g/kw.h)	275.1	281.5
Valve clearance (mm)	0.10--0.15
PTO Model	Crankshaft orCamshaft
Starting system	electric
PTO rotation direction	It is clockwise as viewing from the flywheel end
Battery Capacity(V,AH)	12V-36AH
Dimension(mm)	520x520x570
Net weight(kg)	45
20FT	176

	KA400

Model	KA186F
Type	Single-cylinder,vertical,4-stroke air-cooled diesel engine
Combustion system	Direct lnjection
Bore X Stroke(mm)	86x70
Displacement(cc)	406
Speed(rpm)	3000	3600
Max.output(kw)	6	6.3
Rated output(kw)	5.7	6
Max.no-load speed(r/min)	108%
Min.no-load speed(r/min)	1300
Fule	0# or -10#light diesel oil
Fule oil tank volume(L)	5.5
Lubricatiom oil volume(L)	1.65
Fule oil consumption rate(g/kw.h)	275.1	281.5
Valve clearance (mm)	0.10--0.15
PTO Model	Crankshaft orCamshaft
Starting system	recoil
PTO rotation direction	It is clockwise as viewing from the flywheel end
Battery Capacity(V,AH)	12V-36AH
Dimension(mm)	520x520x570
Net weight(kg)	45
20FT	176
