Diesel Engine /8hp Small Diesel Engine
- shanghai
- T/T D/P D/A
You May Like
Product Details
| Usage | Automobile | Fuel | Diesel | |
| Stroke | 4 Stroke | Cylinder | Single Cylinder | |
| Cold Style | Other, Air-cooled | Start | Electric Start | |
| Place of Origin | Jiangsu, China | Brand Name | KAIAO | |
| Model Number | KA186FA |
Product Description
Product DescriptionEngine Type:Diesel engine with Single-cylinder, vertical, air-cooled, direct injection
Bore*stroke(mm):86 *72
Piston displacement(L):0.418
Compression ratio:19:1
Rated power/Rated speed(KW/rpm):5.7/3000 6.3/3600
Max.No-load speed(r/min):108%
Min.No-load speed(r/min):1300
Lubrication system:Spring
Engine starting system:Recoil and hand-operated/Electrical
Output terminal rotation:AnticlockWise
Fuel oil model:Summer:0#, Winter:-10#
Fuel tank capacity(L):5.5
Fuel consumption rate/speed(g/KW.H/r/min):275.1/3000 281.5/3600
Oil consumption rate(g/KW.H):4.08
Oil No.:SAE10W-30, 15W-40
Valve clearance mm:0.10-0.15
Lube oil capacity(L):1.65
Starting motor capacity(V, kw):12V 0.8kw
Charging generator capacity(V, A):12V 3A
Battery capacity(V, AH):12V-36AH
Dimension(L*W*H):420*440*495
Net weight(kg):47
