Specifications
RV-7032 car parking system7inch LCD monitor
Back&dome camera with 120 field view, IR
20m/15m AV cable
RV-7032 7inch car parking system with 7inch LCD monitor&backup camerafor heavy duty machinery
Standalone monitor
7" TFT-LCD MONITOR
Ratio: 16:9/4:3
System: PAL/NTSC auto switch
Audio input: 1 way
Video input: 2 way
Auto backup: V2
Adjustable image brightness/color/contrast
With remote control and OSD menu
Power supply: DC12V (DC24V optional)
Current: 0.7A
Luminance: 300-400/m2
Installation: (stand bracket, Air-container Vent, headrest, Z-clip optional)
Accessories: remote control 1 pc, cable 1 pc
headrest frame, universal stand
Two Camera
Image Sensors: 1/4" OV7950 /1/3"OV7949/1030
TV System:PAL / NTSC
waterproof rate:Ip67
Effective Pixels:628x582 pixels / 656×492 pixels
Resolution:420TV lines
Minimum Illumination:1.0Lux / F1.2
Pin Lens:f=3.6mm / F = 2.0
Lens Angle:120°
Vertical Sync. Frequency:50Hz / 60Hz
Video Output:1.0vp-p, 75Ohm
Power Supply:DC12V
Current Consumption:≤200mA
Electronic Shutter:1/60 ~ 1/10,000 Seconds
Gamma Consumption:0.45
S/N Ratio:Better than 48Db
Scanning System:2:1Interlace
Operating Temperature:-20°C~70°C ,RH95% MAX
Storage Temperature:-40°C~85°C ,RH95% MAX
Package included:
- 7" TFT LCD Color monitor x 1
- Metal bracket x 1
- Remote controller x 1
- Color bus camera x 1
- Color dome camera x 1
- 20m connection cable x 1
- 15m connection cable x 1
