UF Membrane Water Filter
US$ 3,000 - 6,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Vliya
Model Number:
ultrafiltration
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/Shenzhen/HongKong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Membrane Ultrafiltration Drinking Water Mineral Water RO Treatment PlantUS$ 3,000 - 6,000MOQ: 1 Set -
River Water Treatment uf Membrane MachineUS$ 3,000 - 6,000MOQ: 1 Set
-
UF Purifier Treatment UF Water Equipment Water Treatment MachineUS$ 3,000 - 6,000MOQ: 1 Set
-
Ultrafiltration System Pure Water Treatment Machine With RO SystemUS$ 3,000 - 6,000MOQ: 1 Set
-
UF System/Super UF SystemUS$ 120 - 150MOQ: 20 Sets
Place of Origin
Guangdong, China
Brand Name
Vliya
Model Number
ultrafiltration
Product Description
1.Description of UF membrane water filter
Ultrafilters (UF) can be obtained either as spirally wrapped membrane devices or as a bundle of hollow fibres. The nominal molecular cut-off (NMWCO) range for ultra filtration devices is between 5,000 and 150,000 Daltons.
They can be used in both pre-treatment and polishing duties in water purification systems. For pre-treatment a UF device with a (NMWCO) of between 80,000 and 150,000 Daltons would be used for the removal of colloidal contaminants. For the removal of Endotoxin material from purified water, the pore size would be reduced to between 5,000 and 20,000 Daltons.
To maintain performance, UF membranes will require frequent back-flushing and ocassional cleaning using chemicals. For critical applications, hot water can be used to thermally disinfect the membranes; this will depend on the materials of construction used in the UF membrane.
Product Application
2.Application of UF membrane water filter
| 1 Solvents used in the chemical material production process and cleaning process; |
| 2 Ultrapure materials and chemical solvents; |
| 3 Laboratory and pilot plant; |
| 4 Materials used in electronic semiconductor, integrated circuit boards; |
| 5 Production, processing and purification of quartz, silicon materials ; |
| 6 High purified ink, inkjet of fax and printer, nano-ink; |
| 7 Textile, chemical industry, process water / chemical recycled water, chemical products manufacturing purification and preparation of water ; |
| 8 Food and beverage industrial water, purified drinking water, beverages,beer,ect. |
Product Flow Chart
3.Flow chart of UF membrane water filter
NOS. |
Items |
Information |
|
1. Pre-treatment
|
Source water tank |
Store source seawater, let it have a sedimentation before entering the plant. |
Booster pump |
Provide power for pre-treatment part. |
|
Sand filter |
Remove turbidity, SS matter, organic matter, colloid, etc. In the water |
|
Active carbon filter |
Remove color, free chloride, organic matter, harmful matter, etc. |
|
Dosing system |
Detail dosing system will be decided by: source quality & treated water quality requirements. Normal including: inhibitor dosing, PH dosing, reducing dosing, germicide dosing. |
|
2. Minerral water plant |
PP filter |
Prevent large particles, iron, dust, SS matter, impurity into the RO membrane. |
UF system |
Remove high molecular-weight substance, micro organic, colloid |
|
UF water tank |
Store UF water and get ready for next treatment. |
|
3. Control system |
Control panel |
Assembled by factory. Auto type. |
PLC mode |
Adopt Mitsubishi from Japan, good quality. |
|
Touch screen |
Make use of WeiNview from Taiwang. Convenience for user to operate. |
|
Electricity components |
Schneider/Omron from German. |
|
Plant skid |
Anti corrosion paited. |
|
Product Feature
3.Feature of UF membrane water filter
| 1.The using material is environmentally friendly,and safe. |
| 2.Super accuracy filtration and using long time |
| 3.The test for pressure is Complianced with the standard of NSF |
| 4.Strong anti-pollution for the ultrafiltration membrane with efficient adsorption |
