Direct Manufacturer 12dBi GSM900/CDMA800 panel base station vertical polarization antenna
Direct Manufacturer!
More spec. for you choose!
Can be cusomized!
Electrical specifications | |
Frequency Range(MHz) | 806-960Mhz |
Polarization | Vertical |
Impedance | 50 Ohm |
Gain (dBi) | 12dBi |
Radiation | Omni |
Half power Beam Width | H:65 V:30 |
Front to back ratio | ≥18 |
VSWR | ≤1.5 |
Maximum input power (W) | 200w |
Lighting Protection | Direct Ground |
Mechanical specifications | |
Connector | N Female |
Dimensions (Height*Width*Depth) | 700mm*280mm*80mm |
Packing weight (kg) | 6kg |
Radiating Material | UPVC |
Operating temperature (℃) | -40~60 |
Mounting hardware (mm) | Ø35-75mm |
Shipping:
Express delivery: UPS / DHL / TNT / FEDEX / EMS/Air freight /Shipping to meet customers' need.
