Description
The optical fiber unit is positioned in the centre
Two parellel fiber reinforced plastics(FRP)as placed at the two sides.
The cable is completed with a blackor color LSZH sheath
Characteristics
Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber
Simple structure,light weight and high practicability
Novel flute desig, easily strip and splice, simplify the installation and maintenance
Low smoke zero halogen and flame retardant sheath
Fiber colour Code
01- Blue |
04- Brown |
07- Red |
10- Purple |
|
02- Orange |
05- Grey |
08- Black |
11- Pink |
|
03- Green |
06- White |
09- Yellow |
12- Aqua |
|
Dimensional Characterstics
Part Number |
Fiber Count |
Nominal Cable Diameter |
Nominal cable weight |
KTFTTH-IQ-WH-0209 |
2 |
(2.0±0.2) x (3.0±0.2) |
8.0 |
KTFTTH denotes Kontoon FTTH cable; IQ denotes colored fiber; WH denotes white sheath;
02 denotes 2 coloured fibers, 09 denotes singlemode G652 fibers
Mechanical & Environmental Characteristics
Item |
Characteristics |
Short-term Tensile Load |
200N |
Long-term Tensile Load |
100N |
Short-term Crush Load |
1000N/100mm |
Long-term Crush Load |
300N/100mm |
Minimum Static Bend Radius |
15mm |
Minimum Dynamic Bend Radius |
30mm |
Operation Temperature |
-40°C~+60°C |
