Help CenterTBC P1004 GEPON ONT
Related Products
Specifications
1: EPON ONU/ONT2 :positioned to support any FTTH infrastructure
3: four 100Mbps ethernet port
Abiding by IEEE802.3ah, GEPON ONT P1004 meets relevant requirements of GEPON OUN regulated in Technical Requirements of YD/T1475-2006—Ethernet-Based EPON and ChinaTelecom EPON Technical
Requirements. Through hi-speed EPON access, P1004 can provide users Internet services and the
service of accessing the enterprise network
|
Attributes
|
P1004 |
|
|
User trial interfaces |
four fixed 10/100M BASE-T auto-adaptable RJ45 interfaces |
Management configuration
|
arious management modes such as CLI, Web, SNMP, TELNET and cluster RMONv1, group 1, group 2, group 3 and group 9 SSHv1/v2 Upgrading the software and the bootrom through TFTP and FTP Local or the server’s syslog logs Command prompt in English or in Chinese Network testing tools such as ping and traceroute Debug output |
PON interface Type |
A 1Gbps transmission rate with downlink and uplink symmetry Network coverage diameter: 30 kilometers of the optical interface: SC/PC Hi-sensible optical receiver: Not less than -26dBm Radiation power: 2-7dBm Security: ONU authentication mechanism |
Physical structure
|
206.0 mm(W) x 135.5 mm(D) x 41.8 mm(H) Installation: desktop Requirements of dust prevention: dust’s diameter > 5µm; dust concentration ≤3×104 corpuscle/m3 |
Standard IEEE |
IEEE 802.3ah PRC Community Industry Standard (YD/T 1475-2006) 802.1D, Spanning Tree IEEE 802.1Q, VLAN IEEE 802.1w, RSTP Ethernet – II, Ethernet-SNAP |
Environment requirements |
Working condition: -5°C~45°C; 5%-95% no condensation Storage condition: -20°C~70°C; 5%-95% no condensation |
VLAN |
Port-based VLAN GVRP IEEE 802.1Q VLAN |
Power Source
|
Type of the power adapter: the on-off power adapter Input voltage: 110V~240V,50Hz ±5% Output voltage:12W, 1.5A Fluctuated range of the input voltage: ±20% (domestic); ±10% (international) Fuse: Installing the irrecoverable temperature fuse (or temperature resistance) at the input terminal Over-current protection and overvoltage protection Power consumption: Up to 12W |
QOS |
Backpressure flow control (half duplex) IEEE 802.3x flow control (full duplex)Head Of Line (HOL) prevention mechanism IEEE p802.1p, CoS Four transmission queues on each port are mapped to eight priority values of 802.1p. WR, SP and FIFO Rate contro
|
Dielectric strength
|
Power source to hull: AC 3000V, lasting one minute Power source to network port: AC 3000V, lasting one minute |
|
Reliability
|
Unidirectional Link Detection (UDLD) Dying-Gasp |
Thunder prevention |
Power source: differential mode 2.5KV, common mode 4KV Network port: common mode 1KV |
Network security |
EEE 802.1x, port-based access control Supporting the local and remote authentication, EAP termination or transparent transversal CHAP and EAP authentication Limiting the maximum number of users on each port Protecting the port Controlling the storm of packet |
EMC |
GB9254-1998(idt CISPR22:1997) |
