Help CenterChinese TOP Supplier Famous MWM Marine Genset 550KW Price 60HZ BV Approved
Related Products
-
Chinese TOP Supplier Famous Shangchai Marine Genset 250KW Price BV ApprovedUS$ 14,000 - 20,000MOQ: 1 Set -
Chinese Top Supplier BV Approved Famous Brand 200kw MWM Marine Diesel Generator PriceNegotiableMOQ: 1 Set
-
China Top Factory 1000KW MWM Generator PriceNegotiableMOQ: 1 Set
-
1000kw MWM Marine Diesel GeneratorUS$ 6,000 - 50,000MOQ: 1 Set
-
Hot Sale 750kw MWM Marine Diesel Generator PriceUS$ 6,000 - 50,000MOQ: 1 Set
Specifications
1,one year warranty and global service2,BV certificate
3,ATS or AMF
4,low fuel consumption
We are specific in this field for more than 20 years and the top vvip supplier on alibaba!
We have our own factory and many senior engineers.
Our products can meet the needs of different voltage and frequency.
If you have any demands not hesitate to contact us!
Criterion
- GB/T13032-1991
- ISO9001:2008 Quality Control System
- CCS approved
Engine Specification
MWM Diesel Engine
Technical Data
Engine Model |
TBD604BL6 |
Number of Cylinders |
6 cylinders in line |
Cycle |
4 stroke |
Aspiration |
Turbocharged and after cooled |
Bore×Stroke |
170 x195 mm |
Displacement |
26.58 L |
Compression ratio |
14:1 |
Prime Power/Speed |
637KW/1800rpm |
Speed Governor |
electrical |
Cooling System |
By heat exchanger |
Fuel Consumption at 100% Load |
197 g/kw.h |
Starter Motor |
DC24V |
Alternator Specification
STAMFORD Alternator (Standard)
Technical Data
Alternator Model |
LVM634B |
Prime power |
557KW |
Frequency/speed |
60HZ/1800rpm |
Exciter type |
Brushless, Self-excited |
Power factor |
0.8 |
Insulation Grade |
H |
Protection Grade |
IP23 |
Phase / wire |
3 phase 4 wires |
control system
MODEL:KCMII G
*engine start/stop
*engine coolant temperature
*oil pressure and temperature
*tachometer
*coolant temperature alarm
*oil pressure alarm
*battery charging indicator
*generator to be protection from overload and overheat
