Specifications
1.generator diesel 25kw2.One year warranty
3.ISO,CE certificate
4.reliable performance
1.diesel generator 25kw general feature:
1) Equipped with battery charger and 24V high performance maintenance-free lead-acid starting batteries and connecting cables.
2) Equipped with industrial silencer and flexible exhaust hose.
3) Equipped with 8-hours operation base fuel tank.
4) Equipped with PEOPLE MCCB circuit breaker.
5) Designed to Comply with ISO8528/GB2820.
6) Powered by Cummins engine and coupled with Marathon alternator.
We are the top VIP supplier on Alibaba ,
authorized by famous certification authority-BV ( Bureau Veritas )!!!
CE approved radiator cooled deutz soundproof generator diesel 25kw
Specifications
2.Technical Data
Deutz Diesel Engine
Technical Data
Engine Model |
D226B-3D |
Configuration |
4 cycle , 3 cylinders in line |
Aspiration |
Natural |
Bore×Stroke |
105x120 mm |
Rated speed |
1500rpm |
Displacement |
3.0 L |
Prime Power |
30KW |
Speed Governor |
Mechanical/Electronic |
Cooling System |
Closed water-cooled |
Speed Stability (%) |
≤5% |
Fuel Consumption at 100% Load |
≤208g/kw.h |
Starter Motor |
DC24V |
Marathon Alternator
Technical Data
Alternator model |
GM-30-4 |
Alternator manufacturer |
Marathon |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
30 kW |
Rated speed |
1500 RPM |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V(Available with customer requirements) |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
4.Warranty
Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.
5.picture
