Help Center20%off Factory Sale 40kw Deutz Alternator ac Single Phase Power Generator
Related Products
-
450kw Diesel Generator Powered by Deutz Engine With CE & ISOUS$ 38,000 - 45,000MOQ: 1 Set -
CE Approved Manufacturer 100kva European Brand Diesel Generator Powered by Deutz EngineUS$ 5,000 - 15,000MOQ: 1 Set
-
Good Quality Air Cooled Diesel Genset Deutz 15kva With CEUS$ 3,000 - 4,500MOQ: 1 Set
-
Best Quality 3-cylinder Diesel Engine DeutzUS$ 7,500 - 9,500MOQ: 1 Set
-
20% off Manufacturer Sale 150kva 6 Cylinder Deutz Electric GeneratorUS$ 5,000 - 15,800MOQ: 1 Set
Specifications
1.ac single phase power generator2.ISO,CE certificate
3.deutz technology
4.global service for 12 month
1. Deutz diesel power generator general feature :
1) Brand NEW DEUTZ engine 226B, 1015 Series, with start motor.
2) Brushless alternator, Single bearing, Flange connection, IP23, H insulation class, with AVR.
3) Auto control panel with LCD display, and design patent for the Control Cabinet.
4) Engine mounted battery-charging alternator, Genset with battery charger of main supply
5) Circuit Breaker, Exhaust Silencer.
6) Copper Radiator for 50C ambient temperature
20%off factory sale 40kw deutz alternator ac single phase power generator
Specifications
2. deutz engine Technical Data:
Engine Model |
TD226B-3D |
Configuration |
4 cycle , 3 cylinders in line |
Aspiration |
Turbochargerd |
Bore×Stroke |
105x120 mm |
Rated speed |
1500rpm |
Displacement |
3.0 L |
Prime Power |
45KW |
Speed Governor |
Mechanical/Electronic |
Cooling System |
Closed water-cooled |
Speed Stability (%) |
≤5% |
Fuel Consumption at 100% Load |
≤208g/kw.h |
Starter Motor |
DC24V, |
Marathon alternator technical Data:
Alternator model |
GM-40-4 |
Alternator manufacturer |
Marathon |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
40 kW |
Rated speed |
1500 RPM |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V(Available with customer requirements) |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
3.Diesel power generator warranty:
Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.
4. Document:
1) Alternator operation and maintenance manual 1PC
2)Engine operation and maintenance manual 1PC
3)Generator Overall drawings of the set 1PC
4)Electrinic system drawing 1PC
5)Bench test 1PC
6)Packing list 1PC
5.picture
