Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > OEM 100kva 150kva 200kva Silent Cummins Engine Diesel Generators Prices
OEM 100kva 150kva 200kva Silent Cummins Engine Diesel Generators Prices
US$ 20,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Cummins
Model Number:
BC-200S generators prices
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
28kva Open Cummins Engine Generator Electric SetUS$ 5,500 - 6,500MOQ: 1 Set -
40Kva Generator Cummins Engine Diesel for SalesUS$ 4,500 - 25,000MOQ: 1 Set
-
China Cummins Engine Generator SetUS$ 17,189 - 18,898MOQ: 1 Set
-
Cummins Engine Diesel Generator / Cummins Engine Diesel Genset / Cummins Engine Generating SetUS$ 3,999 - 19,999MOQ: 1 Set
-
200kw Cummins Engine Generator Set With CE ISO EPAUS$ 18,500 - 18,999MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
Cummins
Model Number
BC-200S generators prices
Output Type
AC Three Phase
Speed
1500rpm
Frequency
50HZ
Rated Power
200kva
Rated Voltage
230/400V
Rated Current
288.68A
OEM 100kva 150kva 200kva Silent Cummins engine Diesel Generators Prices
| Product Overview | |
| 1) Brand-Cummins | |
2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR. | |
| 3) Auto control panel with LCD display. | |
| 4) Engine mounted battery-charging alternator,Genset with battery charge of main supply. | |
| 5) Circuit Breaker,Exhaust Silencer. | |
| 6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard. | |
| 7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable. | |
| 8) Skid-mounted bottom 8 hours fuel tank. | |
| 9) Extemal recessed emergency stop button for extra safety. | |
| 10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system. | |
| 200kva Cummins diesel generator | |
| Genset Specification | |
| Genset Model | BC-200S |
| Prime Power(Kw/Kva) | 160/200 |
| Frequency | 50Hz |
| Structure type | Open or Soudproof |
| Dba"@7m | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
| Engine Model | 6CTAA8.3-G2 |
| Alternator Model | STG274H |
| Open type DimensionL*W*H(mm) | 2200*850*1500 |
| Weight(Kg) | 1900 |
| Silent type DimensionL*W*H(mm) | 2400*1100*1700 |
| Weight(Kg) | 2200 |
| Engine Detail | |
| Manufacturer | dongfeng cummins engine Co.,Ltd |
| Model | 6CTAA8.3-G2 |
| Engine speed | 1500rpm |
| Engine Characters | water-cooled,6cylinders in line,4-cycle,direct injection |
| The maximum output(kw) | 183KW |
| Aspiration | Turbocharged |
| Bore(mm)xStroke(mm) | 114*135 |
| Compression ration | 16.5:1 |
| Fuel consumption(L/H) | 40(100%loading) |
| Displacement(Liters) | 8.3 |
| Exhaust air flow(m3/min) | 240 |
| Compress air flow(m3/min) | 16.8 |
| Exhaust gas flow(m3/min) | 32.58 |
| Exhaust highest temperature | 640°C |
| Lube-oil pan capacity(L) | 20 |
| Cooling water capacity(L) | 12.3Liters(Engine only) |
| Voltage for start(V) | 24 |
| Instrument for adjusting speed | Electronically |
| Noise level(A)@7m | less 96dBA(open type) ,less 70dBA(silent type) |
| Alternator Detail | |
| Model | STG274H |
| Output power(Kw/Kva) | 160/200 |
| Number of phase | 3 |
| Power factor(Cos Phi) | 0.8 |
| Number of Pole | 6 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | 0.50% |
| Total haarmonics (TGH/THC) | 4% |
| Wave form:Nema=TIF | 50 |
| Wave form:I.E.C=THF | 2% |
| Bearing | single |
| Coupling | Direct |
Diese engine optional
Alternator optional
Controller optional
products detail photo
