25Kva China Manufacturer Silent Diesel Generator Distributor
US$ 3,052 - 4,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Boomaster
Model Number:
BQ-25S
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3-15kw Water Cooled Single Cylinder Generator SetUS$ 1,800 - 2,200MOQ: 1 Set -
China Silent Diesel Generator SetUS$ 1,999 - 5,999MOQ: 1 Set
-
Denyo 20 KVA GeneratorUS$ 2,500 - 2,900MOQ: 1 Set
-
AC Single Phase Output Type Electric Start for GeneratorUS$ 2,500 - 2,900MOQ: 1 Set
-
AC Three Phase Output Type Super Silent Diesel Generator 20kvaUS$ 2,500 - 2,900MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
Boomaster
Model Number
BQ-25S
Output Type
AC Three Phase
Speed
1500/1800rpm
Frequency
50/60Hz
Rated Power
20Kw/25Kva
Rated Voltage
230/400V
Specifications
1. Quanchai engine2.20Kw/25Kva
3.new products on China Market
4.Prompt Delivery:20 days
5.Gurantee: 18 month
25Kva china manufacturer silent diesel generator distributor
- Technical Data :
| Product Overview | |
| 1) Brand-new engine,w/start motor. | |
| 2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR. | |
| 3) Auto control panel with LCD display. | |
| 4) Engine mounted battery-charging alternator,Genset with battery charge of main supply. | |
| 5) Circuit Breaker,Exhaust Silencer. | |
| 6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard. | |
| 7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable. | |
| 8) Skid-mounted bottom 8 hours fuel tank. | |
| 9) Extemal recessed emergency stop button for extra safety. | |
| 10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system. | |
| 25Kva Quanchai diesel generator | |
| Genset Specification | |
| Genset Model | BQ-25S |
| Prime Power(Kw/Kva) | 2025 |
| Frequency | 50Hz |
| Structure type | Open or Soudproof |
| Dba"@7m | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
| Engine Model | QC490D |
| Alternator Model | STG184F |
| Open type DimensionL*W*H(mm) | 1900x700x900 |
| Weight(Kg) | 500 |
| Silent type DimensionL*W*H(mm) | 2000x900x1040 |
| Weight(Kg) | 600 |
| Engine Detail | |
| Manufacturer | Quanchai engine Co.,Ltd |
| Model | QC490D |
| Engine speed | 1500rpm |
| Engine power | |
| …………Prime power | 22KW(50Hz) |
| Type | vertical,4 cylinder,in-line,water-cooled,four-stroke |
| Aspiration | Naturally aspirated |
| Governor | electrical |
| Bore*Stroke | 90*105mm |
| Displacement | 2.672L |
| Alternator Detail | |
| Model | STG184F |
| Output power(Kw/Kva) | 2025 |
| Number of phase | 3 |
| Power factor(Cos Phi) | 0.8 |
| Number of Pole | 4 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | 0.50% |
| Total haarmonics (TGH/THC) | 4% |
| Wave form:Nema=TIF | 50 |
| Wave form:I.E.C=THF | 2% |
| Bearing | single |
| Coupling | Direct |
- Details of products :
- Related Products:
- Controller System:
- Our Factory :
- Exhibition :
- Certificates :
