Magnetic Drive Pumps High Quality Silicon Carbide Ring Sealing
Silicon carbide ring, silicon carbide seal rings
We JK produce silicon carbide products with high quality. The series of silicon carbide are used in abrasives, refractories, ceramics, and numerous high-performance applications. The material can also be made an electrical conductor and has applications in resistance heating, flame igniters and electromic components. Structural and wear applications are constantly developing.
Series of Silicon Carbide SiC Ceramics-silicon carbide ring
√ Reaction Bonded Silicon Carbide (RBSiC)
√ Recrystalized Silicon Carbide (RSiC)
√ Silicon infiltrated Silicon Carbide (SiSiC)
√ Nitride Bonded Silicon Carbide (NSiC)
√ Sintered Silicon Carbide (SSiC)
Characteristics of Silicon Carbide SiC Ceramics-silicon carbide ring
√ Low coefficient of friction
√ High thermal conductivity
√ Excellent high-temperature strength
√ Excellent wear resistance
√ Excellent thermal shock resistance
√ Excellent corrosion resistance
√ ...
Applications of Silicon Carbide SiC Ceramics-silicon carbide ring
√ Refractory
√ Mechanical seal
√ Sealing strip
√ Seals, bearings
√ Fixed and moving turbine components
√ Semiconductor process equipment
√ Suction box covers
√ Heat ecchangers
√ ...
Technical Parameter of Silicon Carbide SiC Ceramics-silicon carbide ring
| Basic Material Properties. | Silicon Carbide | |
| SiSiC (Sintered) | SiSiC (Reaction Bonded) | |
|
Basic Composition ( Contents ) |
>98.5% SiC | >88% SiC < 12% Si(Free) |
| Density | 3.1 g/cm3 | 3.05 g/cm3 |
| Hardness | 2820 HV | 2500 HV |
| Max. use Temperature | 1750°c | 1300°c |
| Open Porosity | Nil | Nil |
| Closed Porosity | < 2% | < 2% |
Alumina ceramics & Zirconia ceramics
Packaging of silicon carbide ring
√ Standard export packing: carton, wooden case
√ According to customers' specific requirement
Shipping of silicon carbide ring
√ By express: DHL, UPS, Fedex, TNT, EMS...
√ By air
√ By sea
√ Customer's designated forwarder
Any inquiries, please contact me.
