JX-900 Low Pressure Top type Plastic Injection Machine Single Station Vertical lntengrated Machine for Phone Battery Making
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
Best Quality Plastic Injection Moulding Machine Manufacturers JX-350
-
Low Pressure Injection Molding Mobile Phone Housing Injection mold Machine JX-350
-
Cheap Price injection Plastic Molding Machine Battery pack production tool battery welding Usage
-
Thermoplastic Plastic Type and Used Condition used plastic injection molding machine
-
Low Pressure Plastic Molding Machines for Lithium battery Injection Molding
-
JX-1600D /Best Price Manufacturer Battery Factory Molding Machine
Product Details
| Condition | New | Type | Injection Blow Molding | |
| Style | Vertical | Brand Name | JXC | |
| Model Number | JX-900 | Place of Origin | Guangdong, China | |
| Plastic Type | Other, Low pressure hot melt adhesive(electronic special) | Automatic | Yes | |
| Clamping Force | Max 1.2 Ton | Opening Stroke | 150mm | |
| Power(W) | 4500w | Certification | CE ISO9001ROSH | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
JX-900 low pressure plastic injection machine
[Machine features]
1 . Single station vertical injection system. especially on the left and right parallel continuous wire outlet mold design is more reasonable and reliable.
2. Console and sol system adopts the integral layout, flexible use.
3. Consoler touch-screen display, with multi-language PLC control system.
4. Glue gun is ditectiy connected with sol cylinder by a hose: compact structure, stable plastic injection.
5.Injection pressure adjustable, DELTA temperature control module, accurately mornitors the temperature conditions.
6.The hands switch clamping and safety grating, emergency stop switch, to ensure safe operation.
7.The mold is convenient to replace, workbench buits product ejection device, convenient to extract products.
[Specifications]
Plastic machinery | JX-900 |
Size(mm)Machine(kg) | |
WorkStation Height(mm) | 900 |
Plant View(mm) | 1040×920 |
Packing(mm)Size(kg) | 1060×1050×1700(400Kg) |
Melting Tank | (5Liter)×1 |
Gun & Tip Angle | (36.4°60°90°)optional |
Heated Hose | JX-ZH-16-C×1 |
Electricity | 200-240VAC/1Phase/50 or 60Hz |
Temperature Control Zones | 3 |
Temperature Range | 70℃- 260℃ |
Max.Power(Kw) | 4.5 |
Working pressure(Mpa) | 0.5(Mpa)~0.8(Mpa) |
Air Consumption | 0.1m3/min |
Clamping Device | Pneumatic |
Clamping Force | Max.1.2Ton |
Clamping Stroke(mm) | 150 |
Control System | touch screen |
Standard Mold Set Size(mm) | 230×120×150 (25Kg) |
Max.Mold Set Size(mm) | 300x200x150 |
Max. Part Size(mm) | 60×50×18 |
