Home > Products > Low pressure injection molding machine > JX-525 / Desktop Low Pressure Side Type Integrated Machine What is Injection Moulding Machine
JX-525 / Desktop Low Pressure Side Type Integrated Machine What is Injection Moulding Machine
- 300 Set / Sets per Month
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
JX-2200 / Side Duplex Split Plastic Moulding Machine JX-2200
-
Low pressure molding machine Vertical lntegrated low pressure molding equipment low molding
-
Injection molding machine over mold injection molding machine over mold injection molding equipment
-
LPMS low pressure molding Injection molding machine over mold injection molding machine over mold injection molding equipment
-
low pressure molding machine special type low pressure molding machine Top type low pressure injection molding machine
-
Low Price Function Phone Battery PCB Tester Nokia Function Phone Battery Making Testing Machine
Product Details
| Condition | New | Type | Injection Blow Molding | |
| Style | Vertical | Brand Name | JXC | |
| Model Number | JX-525 | Place of Origin | Guangdong, China | |
| Plastic Type | Other, Low pressure hot melt adhesive(electronic special) | Automatic | Yes | |
| Injection Weight | 80-150g/min | Clamping Force | Max 1.2Ton | |
| Opening Stroke | 125mm or 150mm option | Power(W) | 3500w | |
| Certification | CE ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Pressure Side Type Integrated Machine What is Injection Moulding Machine
[Features]
1, single station Side dispensing system.
2, the plastic cylinder built-in Desktop Design One-body aircraft.
3, equipped with two guide rods die, less investment and maintenance costs.
4, the text screen display, operation is convenient.
5, Note glue gun and glue cylinder direct connection. Compact structure, stable dispensing
6, plastic injection pressure adjustable, OMRON temperature controller, precise monitoring of temperature conditions.
7, equipped with a safety light curtain and the start button with both hands, to ensure safe operation
8, mold production miniaturization allow conversion more convenient.
[Specifications]
Plastic machinery | JX-525 |
Size(mm)Machine(kg) | 760x935x895(230kg) |
WorkStation Height(mm) | 840 |
Plant View(mm) | 760x930 |
Packing(mm)Size(kg) | 850x1040x950(265kg) |
Melting Tank | (3Liter)×1 |
Gun & Tip Angle | (36.4°60°.90°)optional |
Heated Hose | N/A |
Electricity | 200-240VAC/1Phase/50 or 60Hz |
Temperature Control Zones | 2 |
Temperature Range | 70°-260°℃ |
Max.Power(Kw) | 3.5 |
Working pressure(Mpa) | 0.5(Mpa)~0.8(Mpa) |
Air Consumption | 0.1m3/min |
Clamping Device | Pneumatic |
Clamping Force | Max.1.2Ton |
Clamping Stroke(mm) | 125mm or 150mm optional |
Control System | Text display |
Standard Mold Set Size(mm) | 180×100×150(16kg) |
Max.Mold Set Size(mm) | 300×120×150 |
Max. Part Size(mm) | 50×45×8 |
1.Q: What is the product ?
A: It is a plastic injection machine,can encapsulate and protect the electronic components.
2. Q: What about the quality guarantee and after-sale service ?
A: we prrovide one year quality guarantee , full time after-sale service .
3.Q: we want to open an automating system for 18650 26650 battery , how it can do that ?
A: Yes , we can provide you the battery automating system and solution .
If you want to know more,please contact me:
Name: Wendy Xie
Tel/Whatsapp: +8615623046687
Wechat: xqw1117
QQ: 2066875151
