JX-1800H single-station side of the supercharger One body aircraft low pressure plastic injection molding LPMS low pressure molding system plastic low pressure molding equipment low pressure molding system low pressure molding resin hot melt adhensives low pressure
[Features]
1 single-station Side dispensing system. For various dispensing encapsulation product design models, especially for more complex multi-cavity mold design with slide mechanism gives a much greater application space.
2 console and sol system uses the overall layout.
3 Note glue gun and glue cylinder direct connection. Compact structure, stable performance simplicity.
4 clamping cylinder using liquid had connections. Greater clamping force for dispensing larger, large plastic injection products in large quantities into the production.
5 Computer touch screen display, multi-language PLC control system.
6 plastic injection pressure is adjustable, DELTA temperature control module, the accurate detection of temperature conditions. 7 hand switch mold and safety grating, emergency stop switch, ensure safe operation.
8 Configuring mechanical ejection system, and the top of the pressure control system.
9 machine running boards by ergonomic design for easy operation of production.
[Specifications]
Plastic machinery |
JX-1800H |
Size(mm)Machine(kg) |
975x1150x1880 (400kg) |
WorkStation Height(mm) |
840 |
Plant View(mm) |
1700x1000 |
Packing(mm)Size(kg) |
1100x1200x2000 (450kg) |
Melting Tank |
(5Liter)×1 |
Gun & Tip Angle |
(36.4°60°.90°)optional |
Heated Hose |
N/A |
Electricity |
200-240VAC/1Phase/50 or 60Hz |
Temperature Control Zones |
3 |
Temperature Range |
70℃- 260℃ |
Max.Power(Kw) |
4.5 |
Working pressure(Mpa) |
0.5(Mpa)~0.8(Mpa) |
Air Consumption |
0.1m3/min |
Clamping Device |
Air Qver Oil |
Clamping Force |
Max.10Ton |
Clamping Stroke(mm) |
125mm or 150mm optional |
Control System |
touch screen |
Standard Mold Set Size(mm) |
230×120×150 (25kg) |
Max.Mold Set Size(mm) |
300×200×150 |
Max. Part Size(mm) |
100×90×18 |
