JX-525 Manufacturing of Machinery Plastic Injection Molding Machine
- Shenzhen
- T/T Money Gram Credit Card PayPal
You May Like
-
Best Price China Manufacturer Low Pressure Injection Molding Machine JX-920
-
Battery Making Plant Housing Encapsulating Verticle Single Station Side Type Low Pressure Injection Molding Machine JX-1600
-
Factory Direct Sale Electronics Lithium Battery Encapsulation Single Station Side Low Pressure Inject Molding Machine JX-1600A
-
Low Price High Quality Low Pressure Injection Machine Electronics Lithium Battery Encapsulation Single Station Side Typ JX-1600A
-
For Sale Must Buy for Battery Manufacturing Plant Low Pressure Inject Mould Machine Housing Encapsulating JX-1600
-
Mobile Battery Housing Encapsulating Machine Low Pressure Injection Molding Single Station Side Type Integrated Machine JX-350
Product Details
| Condition | New | Type | Injection Blow Molding | |
| Style | Vertical | Brand Name | JXC | |
| Model Number | JX-525 | Place of Origin | Guangdong, China | |
| Plastic Type | Other, Low pressure hot melt adhesive(electronic special) | Automatic | Yes | |
| Injection Weight | 80-150g/min | Clamping Force | Max 1.2Ton | |
| Opening Stroke | 125mm or 150mm option | Power(W) | 3500w | |
| Certification | CE ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
JX-525 Manufacturing of Machinery Plastic Injection Molding Machine
[Features]
1, single station Side dispensing system.
2, the plastic cylinder built-in Desktop Design One-body aircraft.
3, equipped with two guide rods die, less investment and maintenance costs.
4, the text screen display, operation is convenient.
5, Note glue gun and glue cylinder direct connection. Compact structure, stable dispensing
6, plastic injection pressure adjustable, OMRON temperature controller, precise monitoring of temperature conditions.
7, equipped with a safety light curtain and the start button with both hands, to ensure safe operation
8, mold production miniaturization allow conversion more convenient.
[Specifications]
Plastic machinery | JX-525 |
Size(mm)Machine(kg) | 760x935x895(230kg) |
WorkStation Height(mm) | 840 |
Plant View(mm) | 760x930 |
Packing(mm)Size(kg) | 850x1040x950(265kg) |
Melting Tank | (3Liter)×1 |
Gun & Tip Angle | (36.4°60°.90°)optional |
Heated Hose | N/A |
Electricity | 200-240VAC/1Phase/50 or 60Hz |
Temperature Control Zones | 2 |
Temperature Range | 70°-260°℃ |
Max.Power(Kw) | 3.5 |
Working pressure(Mpa) | 0.5(Mpa)~0.8(Mpa) |
Air Consumption | 0.1m3/min |
Clamping Device | Pneumatic |
Clamping Force | Max.1.2Ton |
Clamping Stroke(mm) | 125mm or 150mm optional |
Control System | Text display |
Standard Mold Set Size(mm) | 180×100×150(16kg) |
Max.Mold Set Size(mm) | 300×120×150 |
Max. Part Size(mm) | 50×45×8 |
