Functional Type Unified Fixed Ultrasonic Flow Meter TUF-2000SW

Item

Performance and Parameter

Main Unit

Principle

transit-time ultrasonic flowmeter

Accuracy

1%

Display

2 line x 20 character LCD with backlight

Operation

Support 16 key light touch keyboard and the Simulation keyboard software

Signal Output

Isolation RS-485 output;

1 channel isolation OCT output;

1 channel isolation 4-20mA output (two-wire system)

Signal Input

Three channel 4—20Am analog signal input

Data interface

Insulate RS485 serial interface, upgrade the flew meter software by computer,

support the MODBUS, METER-BUS etc.

Pipe Condition

Pipe Material

Steel, Stainless steel, Cast iron, Copper, Cement pipe, PVC, Aluminum, Glass

steel product, liner is allowed.

Pipe Diameter

15---6000mm

Straight length pipe

Transducer installation should be satisfied: upstream10D, downstream 5D,

30D from the pump.

Measuring Medium

Type of Liquid

Water (hot water, chilled water, city water, sea water, waste water, etc.); Sewage

with small particle content; Oil (crude oil, lubricating oil, diesel oil, fuel oil, etc.);

Chemicals (alcohol, acids, etc.); Plant effluent; Beverage, liquid food; Ultra-pure liquids; Solvents and other liquids

Temperature

Standard Transducer: -30--90℃; High-temperature transducer: -30--140℃

Turbidity

10000ppm and less than bubble

Flow rate

0--±30 m/s

Flow Direction

Measuring two (plus-minis) direction of flow rate

Working Environment

Temperature

Main Unit: -20--60℃

Flow transducer: -40--160℃;

Humidity

Main Unit: 85% RH

Power Supply

DC24V /AC85-264V
