AC and DC Gear Motor,mirco Gear Motor,gear Reduce Motor,asynchronous Motor
US$ 1 - 100
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Hengbai
Model Number:
F4D120-24GN-20S/4GN5K
Type:
Asynchronous Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
YC SERIES SINGLE-PHASE CAPACITOR START INDUCTION MOTORSUS$ 1 - 200MOQ: 1 Piece -
AC Gear Motor,mirco Gear Motor,gear Reduce MotorUS$ 1 - 100MOQ: 1 Piece
-
Y2 Series Three Phase Induction Motor,IE1 Efficiency Quality ChoiceUS$ 1 - 200MOQ: 1 Piece
-
R Series Inline Helical Gear Reducer Gearbox forUS$ 40 - 10,000MOQ: 1 Piece
-
R Series Inline Helical Gear Reducer Gearbox for Converter/ Mixer Quality ChoiceUS$ 40 - 2,500MOQ: 1 Piece
Brand Name
Hengbai
Model Number
F4D120-24GN-20S/4GN5K
Type
Asynchronous Motor
Frequency
50HZ,60HZ
Output Power
15W,25w,40W,60W,90W,120W
Protect Feature
Totally Enclosed
Phase
Single-phase
Certification
CCC, CE, ROHS
AC Voltage
208-230 / 240 V
Place of Origin
Zhejiang, China
Efficiency
IE 2
Specifications
1.Compact size design2.low rpm High torque output
3.Reliable performance
tal gear
geared motor power range is from 6W-3.7KW(1/125hp to 5hp) ,the speed ratio is from 1:3 to 1:3000,output speed from 0.5rpm-500rpm
Motor :DC4GN40-24-1800
Gearbox: 4GN3K-4GN2000K
speed: 1rpm to 500rpm
DC motors of 24V and 12V available. speed 1800rpm
We are professional Geared motor facotry located in China.
Our geared motor power range is from 6W-3.7KW(1/125hp to 5hp) ,the speed ratio is from 1:3 to 1:3000,output speed from 0.5rpm-500rpm,110V-120V,220V-240V,380V-415V all can be made.Special motors also can be designed and manufactured.
motor Specifications
| type | torque | phase | frequence | votlage | speed | working time | weight |
| F4D120 | 3.2 | 3 | 50hz | 200v | 60 | continuous | 2.5kg |
| 220v | |||||||
| 380v | |||||||
| 6.0 | 60hz | 220v | 72 | continuous | 3.7kg | ||
| 240v | |||||||
| 440v |
