Specifications
1.with capacity of 8-500 t/h2.return sand 3-200 t/h
3.diameter of 2-3.6m selectable
sand washing machine
1.with capacity of 8-500 t/h
2.return sand 3-200 t/h
3.diameter of 2-3.6m selectable
Sand Washing Machine Description:
Sand washer is used for removing dust in sand. It aims at improving the quality of sand.
Advantages of Sand Washing Machine:
the most advantageous factor is that the transmission device isolates with sand and water, which greatly reduces the failure rate.
This sand washer is the perfect equipment for domestic sand wash industry.
The efficient sand washing machine of XSD series is a kind of cleaning equipment of international advanced level for sand and slag pellets, developed on the basis of introducing foreign outstanding technology of the same kind of products.
Sand washer is used to remove the dust in sand. It aims at improving the quality of sand. The materials include the required gravel in building-site, gravel factories, hydropower station and concrete dam site, post and electric pole factory, casting-70 sand, glass factorys quartz sand and refilling pressure sand.
It is widely used for cleaning materials in the following industries: quarry, minerals, building materials, transportation, chemical industry, water conservancy and hydropower, cement mixture station and so on.
Sand Washing Machine Operating Principle
Sand washing machinery drives the impeller in the water groove to move like a circle transmitted by electric motor and decelerator, and then mixes, overturns, cleans and discharges the sand or slag pellets in the water groove.
1. It is of simple structure. The bearing device of impeller drive is separated from water and materials with water, to avoid in a large degree that the bearings are damaged by being soaked with water, sand or some polluted things.
2. When it is used for cleaning sand in quarries, it has many advantages compared with the traditional spiral one.
3.There is little loss for medium-sized and fine sand and stone powder. The grade and the fineness of the sand for construction after being washed can be up to the national standards, such as sand for construction and cobble and broken stones for construction.
4. There are no other wearing parts except the screen mesh.5.It features long service life and few times for maintenan
Type |
Capacity t/h |
Return sand capacity t/h |
Power kw |
Weight kg |
GXS2000 |
8-40 |
3-8 |
4 |
1900 |
GXS2600 |
20-100 |
5-15 |
5.5 |
3500 |
GXS2800 |
50-130 |
8-70 |
7.5 |
5100 |
GXS3200 |
240-300 |
80-130 |
11 |
8800 |
GXS3600 |
280-500 |
100-200 |
15 |
14200 |
The above information is just for your reference, any question pls feels free to contact us.
