double toggle jaw crusher
Feature:
double toggle jaw crusher is widely used to crush various large stones, limestone, granite, basalt, river gravel, etc. It is mainly used to crush hard and medium hard stones in stone mining, metallurgy industry, building material, highway, railway, chemical industry, etc.
Working Principle:
The motor drives pulley, making the movable jaw do periodic movement through eccentric shaft. The angle between toggle plate and movable jaw increases when movable jaw moves up. So the movable jaw moves to the fixed jaw. The stones are crushed in this process. The angle between toggle plate and movable jaw decreases when movable jaw moves down...
Technical parameters:
Model |
Max. Feed Size |
Output Size |
Capacity |
Motor Power |
Weight |
PE-60×100 |
45 |
3-10 |
0.2-0.6 |
1.1 |
0.116 |
PE-150×250 |
125 |
10-40 |
0.6-3 |
5.5 |
0.81 |
PE-250×400 |
210 |
20-80 |
3-13.1 |
15 |
2.8 |
PE-250×500 |
210 |
20-80 |
5.7-31 |
18.5 |
3.37 |
PE-400×600 |
340 |
40-100 |
10-40 |
30 |
6.5 |
PE-430×600 |
400 |
90-140 |
35-60 |
37 |
6.5 |
PE-475×1050 |
400 |
90-140 |
37.5-81 |
55 |
11.7 |
PE-500×750 |
425 |
50-100 |
28.5-62.5 |
55 |
10.3 |
PE-550×900 |
450 |
50-120 |
47-75 |
55 |
7.8 |
PE-600×750 |
500 |
150-200 |
50-100 |
55 |
12 |
PE-600×900 |
500 |
65-160 |
30-75 |
55 |
15.5 |
PE-620×900 |
500 |
95-145 |
31-70 |
55 |
14.3 |
PE-670×900 |
520 |
195-245 |
66-83 |
55-75 |
14.8 |
PE-720×900 |
520 |
195-245 |
66-83 |
55-75 |
14.8 |
PE-750×1060 |
630 |
80-140 |
72-130 |
110 |
29.3 |
PE-800×1060 |
640 |
100-200 |
85-143 |
110 |
30 |
PE-870×1060 |
660 |
200-260 |
181-210 |
110 |
30.5 |
PE-900×1060 |
685 |
230-290 |
100-250 |
110 |
31 |
PE-900×1200 |
750 |
95-165 |
87-164 |
110 |
50 |
PE-1000×1200 |
850 |
195-265 |
197-214 |
110 |
50.6 |
|
|
||||
|
|||||
|
|||||
|
