Tungsten Shaking Table Manufacturer (86-15978436639)
- Qingdao
- T/T Money Gram Credit Card
You May Like
Product Details
| Condition | New | Type | Other, shaking table | |
| Place of Origin | Henan, China | Brand Name | HC Machinary | |
| Model Number | 6-S series |
Product Description
Tungsten shaking table manufacturer
Introduction:
Shaking table is one of the main gravity separation equipments,which is widely applied to separate tungsten, tin, tantalum, niobium and other rare metal, noble metal as well. It can also concentrate iron, manganese and coal, etc. It owns the features of high concentration ratio and sorting efficiency, easy management and adjustment, achieving the final concentrate and tailings in one time.
Technical parameter:
Model | Bed Size | Max. Input Size | Stroke | Water Consumption | Area | Bed Fracture Shape | Power | Weight(kg) | ||
Length | HeadWidth | End Width | ||||||||
Unit | mm | mm | mm | mm | mm | t/d | m2 |
| kw | Kg |
Coarse Sand | 4450 | 1855 | 1546 | 2 | 16-22 | 80-150 | 7.6 | Rectangle | 1.1 | 780 |
Fine Sand | 4450 | 1855 | 1546 | 0.5 | 11-16 | 30-60 | 7.6 | Sawtooth | 1.1 | 780 |
Slime Sand | 4450 | 1855 | 1546 | 0.15 | 8-16 | 10-17 | 7.6 | Triangular | 1.1 | 780 |
