Mineral processing grinding miller
Mineral processing grinding miller introduction:
mineral processing grinding miller is an efficient tool for grinding many materials into fine powder. It is used to grind many kinds of mine and other materials, or to select the mine. It is widely used in building material, chemical industry, etc. There are two ways of grinding: the dry process and the wet process.
Mineral processing grinding miller application:
The mineral processing grinding miller is a key equipment for regrinding. It is widely used for the cement, the silicate product, new type building material, fire-proof material, chemical fertilizer, black and non-ferrous metal, glass, ceramics and etc. Our ball mill can grind ore or other materials that can be grinded either by wet process or by dry process.
Mineral processing grinding miller working principle:
This mineral processing grinding miller is horizontal type and tubular running device, has two warehouses. This machine is grid type and its outside runs along gear. The material enters spirally and evenly the first warehouse of the milling machine along the input material hollow axis by input material device. In this warehouse , there is a ladder scaleboard or ripple scaleboard, and different specification steel balls are installed on the scaleboard, when the barrel body rotates and then produces centrifugal force ,at this time , the steel ball is carried tosome height and falls to make the material grinding and striking.
Mineral processing grinding miller technical parameter:
Model |
Barrel |
Speed |
Capacity |
Feed size |
Output size |
Output |
Motor |
weight |
||
Dia. |
Length |
Type |
Power |
|||||||
YMQG900×1800 |
900 |
1800 |
38 |
1.8 |
0-25 |
0.075-0.6 |
0.44-2.4 |
Y180L-6 |
15 |
4.2 |
YMQG900×3000 |
900 |
3000 |
38 |
2.5 |
0-25 |
0.075-0.6 |
0.7-2.9 |
Y180L-6 |
18.5 |
5.4 |
YMQG1200×2400 |
1200 |
2400 |
37 |
4.8 |
0-25 |
0.075-0.6 |
0.4-5.8 |
Y225M-6 |
30 |
8.2 |
YMQG1200×4500 |
1200 |
4500 |
37 |
5.2 |
0-25 |
0.075-0.6 |
1.4-5 |
Y280M-6 |
55 |
11 |
YMQG1500×3000 |
1500 |
3000 |
29 |
10 |
0-25 |
0.075-0.4 |
2.8-9 |
Y315S-6 |
75 |
16.3 |
YMQG1500×5700 |
1500 |
5700 |
29 |
12 |
0-25 |
0.075-0.4 |
3.1-7 |
Y315M-6 |
90 |
20.7 |
YMQG1830×6400 |
1830 |
6400 |
23.9 |
18.5 |
0-25 |
0.075-0.4 |
6-8.5 |
JR138-8 |
210 |
35.1 |
YMQG1830×7000 |
1830 |
7000 |
23.9 |
21 |
0-25 |
0.075-0.4 |
6-7 |
JR138-8 |
245 |
38 |
YMQG2200×6500 |
2200 |
6500 |
21.4 |
31 |
0-25 |
0.075-0.4 |
14-15 |
JR158-8 |
380 |
50 |
YMQG2200×7000 |
2200 |
7000 |
21.4 |
34.5 |
0-25 |
0.075-0.4 |
14-15 |
JR158-8 |
380 |
67.6 |
