Home > Instruments & Meters > Physical Measuring Meter > Viscometer, Density Meter > Solid Newest Pearl Weld Digital Portable Nodularity Manual

Solid Newest Pearl Weld Digital Portable Nodularity Manual

Name: Solid Newest Pearl Weld Digital Portable Nodularity Manual
Brand: Solid
SKU: 103569787
Availability: InStock

Solid Newest Pearl Weld Digital Portable Nodularity Manual thumbnail-1

Solid Newest Pearl Weld Digital Portable Nodularity Manual photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Beijing, China

Brand Name:

Solid

Model Number:

UpadVX

Contact Supplier Request Quote Chat Now

Solid (Beijing) Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Beijing

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Beijing, China

Brand Name Solid

Model Number UpadVX

Specifications

1 Nodularity guage using
2 Nondestructive Velocity Testing
3 Auto Probe Zeroing Calibration Without Block

Solid newest pearl weld digital portable nodularity manual

1 Nodularity guage using
2 Nondestructive Velocity Testing
3 Auto Probe Zeroing Calibration Without Block

Advantages

What can we do for you?

1, we own 8 years of NDT experience. We can supply the professional solutions for you.

2, Independent R & D team can help your company to undertake the OEM project.

3, Comparing the warranty period with other enterprises we can guarantee the quality for 2 years.

4, Our partners are Qinghua University, BJEA, GE, ALSTOM, REXROTH, SMS and so on. We also can enjoy the government preferential policy. It will be our proud if you become our partner.

5,Our products already were provided to the world. We also have a lot of agents around the world. You can get the biggest discount from Solid NDT company.

Specification

Measuring Range	1.0-1,200mm
Measuring Resolution	0.01mm(< 100mm)/ 1mm(>100mm)
Velocity	500~20,000m/s( 20 fixed velocities)
Delay	Display Delay: -20~3400us resolution: 0.1us Probe Delay : 0~99us resolution: 0.01us
Auto Calibration	Velocity Calibration& Probe Delay Calibration
Linear Error	Horizontal linearity error≤0.1% Vertical linearity error ≤3%
Dynamic Range	≥36dB
Sensitivity Leavings	≥64dB 200mm 2 flat-bottomed hole
Dimension (mm)	24018050
Weight	1.9Kg(including battery pack)
Working Environment	Temperature:-20°C~70°C, Humidity:5%~90%,
Pulse	150V Negative Pulse	Damping :50/150/400Ω
	Pulse repetition frequency PRF could be adjusted
Receiver	Measuring mode:Peak /Verge	Bandwidth:0.3~1 / 0.5~4 /2~15MHz
	Detector Pattern: RF/Full-Wave/Positive /Negative half- wave
	Testing Mode: pulse-Echo/Pulser-Receiver/transmission
	Gain :0 to 110dB Customers define steps 0/0.2/0.5/1/2/6/12
Display	LCD	TFT Color. Display,5 options for variable brightness.
	GUI Theme	Simple/Classical/Gray/Bright Light/ Dark Light
	Screen Update Rate	≥60 Hz
Gate/Measuring/ Alarm	Gate	Two Separated Gates A/B
	Value Display	5 value display areas, one of them is mainly area. Chosen measuring content SA/SB/DA/DB/PA/PB/A%A/A%B/dBtA/dBtB/dBrA/dBrB/SBA/DBA/PBA/LA/LB
	Alarm	Thickness Value Threshold Alarm ,Separated Gate Alarm Logically
Memory	Channelparameters: 20 groups	A Scan: 2000 groups

	A Scan: 2000 groups

Memory
