Solid UFD X5 manufactory digital portable ultrasonic flaw detector
Feature
SOLID UFD X5 digital intelligent ultrasonic detectors uses the latest ultrasonic detector design and manufacturing technology, perfectly blend the science technology and humanity, elegant and fashionable.Using integrated circuit, free charge maintenance and design, high-Speed USB data communications. Widely used in electric power, railway, petrochemical industry, boiler pressure, steel structure steel manufacturing, metallurgy industry, shipbuilding, aerospace and other fields.
Specification
| Measuring Range | 1.0-1,200mm | |||||||||||
| Measuring Resolution | 0.01mm(< 100mm)/ 1mm(>100mm) | |||||||||||
| Velocity | 500~20,000m/s( 20 fixed velocities) | |||||||||||
| Delay | Display Delay: -20~3400us resolution: 0.1us Probe Delay : 0~99us resolution: 0.01us | |||||||||||
| Auto Calibration | Velocity Calibration& Probe Delay Calibration | |||||||||||
| Linear Error | Horizontal linearity error≤0.1% Vertical linearity error ≤3% | |||||||||||
| Dynamic Range | ≥36dB | |||||||||||
| Sensitivity Leavings | ≥64dB 200mm 2 flat-bottomed hole | |||||||||||
| Dimension (mm) | 240*180*50 | |||||||||||
| Weight | 1.9Kg(including battery pack) | |||||||||||
| Working Environment | Temperature:-20°C~70°C, Humidity:5%~90%, | |||||||||||
| Pulse | 150V Negative Pulse | Damping :50/150/400Ω | ||||||||||
| Pulse repetition frequency PRF could be adjusted | ||||||||||||
| Receiver | Measuring mode:Peak /Verge | Bandwidth:0.3~1 / 0.5~4 /2~15MHz | ||||||||||
| Detector Pattern: RF/Full-Wave/Positive /Negative half- wave | ||||||||||||
| Testing Mode: pulse-Echo/Pulser-Receiver/transmission | ||||||||||||
| Gain :0 to 110dB Customers define steps 0/0.2/0.5/1/2/6/12 | ||||||||||||
| Display | LCD | TFT Color. Display,5 options for variable brightness. | ||||||||||
| GUI Theme | Simple/Classical/Gray/Bright Light/ Dark Light | |||||||||||
| Screen Update Rate | ≥60 Hz | |||||||||||
| Gate/Measuring/ Alarm | Gate | Two Separated Gates A/B | ||||||||||
| Value Display | 5 value display areas, one of them is mainly area. Chosen measuring content SA/SB/DA/DB/PA/PB/A%A/A%B/dBtA/dBtB/dBrA/dBrB/SBA/DBA/PBA/LA/LB | |||||||||||
| Alarm | Thickness Value Threshold Alarm ,Separated Gate Alarm Logically | |||||||||||
| Memory | Channelparameters: 20 groups | A Scan: 2000 groups | ||||||||||
| Thickness Logging: 200,000 data sets ,liner | Wave Video: 5 min | Reference Wave:4 | ||||||||||
| Input/Output | Probe Cable: LEMO/BNC | Communication :RS232 | ||||||||||
| Area | Language: Chinese /English | Unit: mm/inch | Clock: Date and Time | |||||||||
| Power | Battery:High power lithium battery ,capable of preventing over-charge and over-discharge | |||||||||||
| Power Indicator:Proportional battery gauge indicating remaining operation time | ||||||||||||
| Working Time:Continuous working over 10 hours | ||||||||||||
| Power adapter:Input 100~240V/50~60Hz output 9VDC/4A | ||||||||||||
| High Grade | USB for Storage | 3 kinds of data report, screenshot , wave, thickness value | ||||||||||
| Gate: | Analysis the details of the wide gate area | |||||||||||
| B Scan: | Thickness/ Shape scan Gray/Color board Design | |||||||||||
| Freezing Curve | Yes | |||||||||||
| Feature Indicator | Measuring of the sound distance wave front & amplitude | |||||||||||
| CSC Curve Calibration | Value correction according to probe angle, pieces thickness and curvature diameter | |||||||||||
| Lock | Single menu independently lock to avoid system adjust related data; | |||||||||||
| Data group could lock to avoid wrong delete | ||||||||||||
| Screen saver | Standby/Character/Power Off | |||||||||||
| Equivalent Curve | DAC curve | Recording 30 calibration points; auto gain; any order calibration; two correction matter calibration/edit ; considering of material attenuation and surface saving factor; 5 estimate curves of adjusted gain, comply to JIS&API standard | ||||||||||
| DGS Curve | DGS Curve fits to three references, includes flat bottomed ,flat-bottomed hole, through holes; considering of material attenuation and surface saving factor, estimating flaw matter; equivalent size/equivalent gain/percentage; | |||||||||||
| Standard Package | Main Body 1 | Straight probe 1 | Angle probe 1 | |||||||||
| Manuel 1 | Carrying Case 1 | Probe Cable 1 | ||||||||||
| Coupling Paste 1 | Power Adaptor 1 | Battery 1 group | ||||||||||
| Optional Accessories | Interface Gate:Applied when flaw detector in a environment which has medium, e.g water | |||||||||||
| Printer:TP serial printer , 3 data report: screen shot , wave , thickness value | ||||||||||||
| Huge capacity battery:Continuous working time: over 20 hours | ||||||||||||
Application:
Ability:
Solid(Beijing) Technology Co.,Ltd is a high-tech business enterprise located in the Beijing , based on research and development, production and marketing of industrial testing equipment .Our team has a solid technical strength and rich marketing experience. We provide reliable industrial testing products and related technical services for our customers in all over the world.
Our advantages:
- All of the items have 1 year warranty(we could change a new one for if there has quality problems,but buyer need to pay for the freight)
- We could prepare the products at once for customers' immediately purchase.
- We offer technic support and lifelong after-sale services.
Delivery Time:
1) After you make the order,we'll contact you and prepare the itme as fast as possible.
2) Finish preparing the model,we ship it for you by DHL/UPS/FedEx/TNT/EMS and give you the tracking number(The process takes about half one day or one day).
3) The shipping time is about 3~5 days by DHL/UPS/FedEx/TNT,10 days by EMS
4) We'll try our best to make the item arrive on time.As the courier,weather and local custom,maybe sometimes it'll be delayed.Your understanding will be highly appreciated
Pls take a Note:
A) The product will be carefully packed by cotton boxes before it's sent out.
B) We'll try our best to make the item arrive on time.As the courier,weather and local custom,maybe sometimes it'll be delayed.Your understanding will be highly appreciated.
C) Pls do not leave not good feedback before contacting us.We're always make the perfect services for our customers all the time.Making promise is the key point in business.
D) The product will be carefully TESTED,then packed by cotton box before it's sent to customer.
Warranty:
All of our products have 1 year warranty.That to say.If the model has any quality problems that you're satisfied,pls do not hesitate to send it back to us for changing a new one or repairing for you.This is our business,and we make the promise.
Contact details:
If you have any questions,pls feel free to e-mail us or call us directly.If nobody answers,pls do not worry.Leave us the message,we'll contact you as fast as possible.Thanks a lot.
Any problems,pls send me feedback or call me for details.We welcome your inquiry.Many thanks.
