80W Mono Crystalline Silicon PV Solar Modules

80W Mono Crystalline Silicon PV Solar Modules photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
NZX
Model Number:
SPM-85SB101
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name NZX
Model Number SPM-85SB101
Material Monocrystalline Silicon
Size 1200*540*30mm
Number of Cells 36pcs
Max. Power 80w

Specifications

80W Mono Crystalline Silicon PV Solar Modules
1,Certification:CE,ISO,ROHS
2,Power:80W/18V
3,High efficiency:17%



80W Mono Crystalline Silicon PV Solar Modules

 80W Mono Crystalline Silicon PV Solar Modules

Specifications



ITEM NO.: SPM-80SB101
Solar Cell: 125*125(mm)poly
Maximum Power(W) 80
Optimum Power Voltage(Vmp) 17.4
Optimum Operating Current(Imp) 4.6
Open Circuit Voltage(Voc) 21.6
Short Circuit Current(Isc) 5.06
Nmber of Cell(pcs) 4*9
Size of Module(mm) 1200*540*30
Packing Configuration 2PCS/CTN,1230*570*85mm
Front Glass Thikness(mm) 3.2
Maxium System Voltage (V) 1000
Maxium Series Fuse Rating(A) 12
Juction Box lp65 rated
Noct 48°C±2°C
Current Temperature Coefficient 0.06±0.01%/K
Voltage Temperature Coefficient -(78±10)MV/K
Power Temperature Coefficient -(0.5±0.05)%/K
Temperature Range  -40°C to +85°C
Tolerance Wattage(e.g.+/-5%) ±5%
Surface Maximum Load Capacity 2400Pa
Allowable Hail Load 23m/s ,7.53g
Weight Per Piece(KG) 8.5
Cell Efficiency >17%
Frame(Material Corners,etc.) Anodized Aluminum Alloy
Backing (Brand Type) TPT
Warranty 3 years for the whole product, for the power,90% for 10 years, 80% for 25 years
Standard Test Conditions AM1.5   1000W/  25 +/-2°C
FF (%) 78%
