Specifications
1. 37'' TFT lcd panel2. 1920*1080 Full HD
3. 500nits 1200:1
4. wide visual angel: 178D
5. professional network ads lcd
|
1 Apply the newest 4 G digital multimedia professor technologies, have excellent visual effect 6. Have a lock, anti-theft functions 7. Widely used in the bus, building and lift room, supermarket, pubic places, train etc | |
Specification model |
US-M3700N |
Panel size |
37″TFT-LCD |
Display area(mm)/mode |
819.4(W)×460.8(H) 16:9 |
Maximum resolution |
1920*1080 |
Display color |
16.7M |
Pixel Pitch(mm) |
0.427(H)×0.427(V) |
Brightness (nits) |
500cd/m2 |
Contrast |
1200:1 |
Visual angle |
178°/178° |
Response time |
5ms |
Life(hrs) |
>60,000(hrs) |
Input and output |
|
Composite video input |
NO |
Y,Pb,Pr/Y,Cb,Cr input |
NO |
S-video |
NO |
HDMI |
NO |
Composite video loop output |
NO |
L/R audio input |
1 ( RCA * 2) |
L/R audio output |
1 ( RCA * 2) |
Speaker |
2×5W(9Ω) |
Video |
|
Color system |
PAL/NTSC/SECAM |
Remote controller |
Special |
Ads input interfaces |
|
USB |
1 ( USB2.0 interface) |
SD |
1 (Compatible MMC/MS) |
CF |
1 |
OSD display( screen menu display) |
|
Menu language |
Chinese/English( multiple language option required) |
Power |
|
Power supply |
AC100~240V 50 /60 HZ |
Maximum power consumption |
180W |
Standby power consumption |
<5W |
Temperature |
|
Working temperature |
0°C~50°C |
Storage temperature |
-20°C~60°C |
Appearance |
|
Panel color/appearance |
White, black, customized |
Panel material |
Metal case SPCC |
Installation |
Floor-standing or wall-mounted |
Detailed functions |
|
Video format |
MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI |
Audio format |
Wave/MP3/WMA/AAC |
Image format |
JPEG/BMP/TIFF/PNG/GIF |
Resolution |
480P/720P/1080P |
Play mode |
Power on, single card auto loop play; classified files auto loop play; multi cards auto loop display et |
Time |
year/month/day/week/h/m/s, in the top right corner (open and close optional) |
Timing open & close |
Per day 5 times, 7 days a week, free time |
Timing play |
7 days a week, free set the play program everyday |
Alarm clock |
Set 5 alarms one day, once ring the alarm, play the specified program |
OTG |
Support copy, delete, remove, rename, build new file among different cards |
Running subtitle |
Can set the play location, word size, color and back-color |
Other function |
Customized |
Upgrade software |
Just put the upgrade file in the storage cards |
