Help Center26 Inch Wall Mount LCD Touch PC With i3 Dual Core
Related Products
-
55" Standing All In One PC Touch Screen With i3 Dual CoreUS$ 600 - 2,000MOQ: 1 Set -
Floor Standing Touch Screen Kiosk, All in One PC, 19''/22''/32''/42''US$ 0.1 - 1,000MOQ: 1 Piece
-
22 Inch Wall Mount Touch Panel LCD AdvertisingUS$ 100 - 900MOQ: 1 Piece
-
32'' Touch Screen All-in-one PC, Rugged Metal Cabinet, LED BacklightUS$ 1 - 5MOQ: 1 Piece
-
42 Inch All In One LCD Touch PC Screen AdUS$ 1,000 - 3,000MOQ: 1 Set
Specifications
Thief-proof wall mounting plateDesigned for 24/7 operation
Timer On / Off
Industrial metal casing & tempered glass
Features
- Built in media player to play almost all formats full HD multimedia files
- HDMI & VGA video input are optional
- Thief-proof
- Designed for 24/7 operation
- Ultra-thin and ultra-light transmission tempered glass or acrylic protective layer
Fully enclosed aluminum frame ,cold-rolled steel design shell
Industrial grade paint technology, smooth and uniform, waterproof and dustproof, anti dust and mill
- Design for both horizontal and vertical use
Ultra-high-fidelity sound, pleasant stereo sound
Remote controller adopt password control,access control and softdog U dish
Support picture split ,video split ,rolling marquee,timing ON/OFF ,25days playlist setting ,ect
Apply the newest 4G digital multimedia professor
Long time stable operation,adopt wide viewing angel technology ,high brightness industrial LCD panel
Specification
| Model | US-AD260WL |
|---|---|
| Screen Size | 26 inches |
| Screen brand | LG or Samsung |
| Display Size(mm) | 575.6(W)×323.5(H) |
| Pixel Pitch | 0.1405mmx0.1405mm |
| Resolution | 1366x768 |
| Brightness | 550 cd / m2 |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 3000:1 |
| Viewing Angle | 178° |
| Colors | 1.07 Billion |
| Input Power Voltage | AC 110-240V (50Hz-60Hz) |
| Working Temperature | 0°C - 50°C |
| Speakers | 2×5W(9Ω) |
| Program Input Port | USB 2.0 x 2 |
| Built-in Flash Memory | 4GB |
| Signal Input Port | VGA,HDMI,Audio (3.5mm) |
| Power Consumption | 270W |
| Supported Media Format |
Video: All Formats (1080P Full HD) Picture: JPG,GIF,BMP,PNG Audio: All Formats
|
| Timer On/Off | Support (Set by daily or weekly) |
| Scrolling Test | Support |
| Split Screen | Support |
| AD Playlist Editor | Support (software free of charge, sync with LCD digital signage via USB flash drive to achieve different functions) |
| Internet Control (work with software) |
LAN, WIFI,3G (Optional) |
| Software | Optional (digital signage software to control LCD display via internet to achieve different functions) |
| Accessories | IR Remote Controller, CD ,Key |
Drawing
i3 Computer Specifications:
-CPU: Intel Core I3-2100 dual core 3.10GHz processor
-Main board: Minix H67-USB3
-Chip: Intel
-Capacity of RAM: 4G, DDR3
-Hard Disk: SATA Rev:2.5 500GB 7200RPM
-Integrated Graphics: Intel HD Graphics Family, 1317MB
-Video: Intel 6 Series Chipset High-Fidelity audio
-Network interface card: Botong Netlink BCM57788 Dual Gigabit Ethernet interface
-Mouse and keyboard: Wireless (Optional)
- Wireless card: Atheros AR9285 802.11b/g/n
Technical Parameter for IR Touch Screen
-Touch Max Resolution: 4096×4096
-Transparency: > 90%, Up to 100%
-Scanning Speed: >50Scans/S
-Response Speed: <12ms
-Touch Type: Horizontal Multi Dot Touch Screen (Vertical way is optional)
-Touch precision: 0.625mm
-Minimum Touch object: ≥5mm
-Touch Intensity: Over 60,000,000 Single Point Touch
-Operation System: DOS, WINDOWS9X/ME/2000/XP/2003/VISTA, LINUX
-Operating Voltage: DC 5V ±5%
-Power Supply: Keyboard Serial Interface
-Power: <1W (Current<200mA)
-Communication: RS-232 Interface Port, USB Port
-Vandal-Proof: Steel Ball (Diameter 63.5mm 1040g Weight) drop from 1040mm, No break
-Temperature Operating: -41°C ~70°C
-Temperature Storage: -50°C ~85°C
-Altitude: 3000m
-Noise: None
-Life Time: >10 Year
Packing information:
1pc touch screen kiosk, 4 pcs keys, remote-controller, wireless keyboard and mouse
