22 Inch Wall Mount Touch Panel LCD Advertising

Name: 22 Inch Wall Mount Touch Panel LCD Advertising
Brand: USER
SKU: 103449101
Availability: InStock

US$ 100 - 900 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

USER

Model Number:

US-AD220WL

Shenzhen USER Special Display Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name USER

Model Number US-AD220WL

Type TFT

Application Indoor

Panel Size 22inch

Max Resolution 1680*1050

Viewing Angle 178°/178°

Pixel Pitch 0.282(H)x0.282(V)

Color 16.7M

Contrast Ratio 3000:1

Brightness 450cd/m2

Response Time 5ms

Input Voltage 80W

Specifications

1.HDMI & VGA video input are optional
2.Designed for 24/7 operation
3.Ultra-high-fidelity sound, pleasant stereo sound

Features

Built in media player to play almost all formats full HD multimedia files
HDMI & VGA video input are optional
Thief-proof
Designed for 24/7 operation
Ultra-thin and ultra-light transmission tempered glass or acrylic protective layer
Fully enclosed aluminum frame ,cold-rolled steel design shell
Industrial grade paint technology, smooth and uniform, waterproof and dustproof, anti dust and mill
Design for both horizontal and vertical use
Ultra-high-fidelity sound, pleasant stereo sound
Remote controller adopt password control,access control and softdog U dish
Support picture split ,video split ,rolling marquee,timing ON/OFF ,25days playlist setting ,ect
Apply the newest 4G digital multimedia professor
Long time stable operation,adopt wide viewing angel technology ,high brightness industrial LCD panel

Specification

Model	US-AD220WL
Screen Size	22 inches
Screen brand	LG or Samsung
Display Size(mm)	496(W)×298(H)
Pixel Pitch	0.282(H)x0.282(V)
Resolution	1680x1050
Brightness	450 cd / m2
Aspect Ratio	16:9
Contrast Ratio	3000:1
Viewing Angle	178°
Colors	1.07 Billion
Input Power Voltage	AC 110-240V (50Hz-60Hz)
Working Temperature	0°C - 50°C
Speakers	2×5W(9Ω)
Program Input Port	USB 2.0 x 2
Built-in Flash Memory	4GB
Signal Input Port	VGA,HDMI,Audio (3.5mm)
Power Consumption	270W
Supported Media Format	Video: All Formats (1080P Full HD) Picture: JPG,GIF,BMP,PNG Audio: All Formats
Timer On/Off	Support (Set by daily or weekly)
Scrolling Test	Support
Split Screen	Support
AD Playlist Editor	Support (software free of charge, sync with LCD digital signage via USB flash drive to achieve different functions)
Internet Control (work with software)	LAN, WIFI,3G (Optional)
Software	Optional (digital signage software to control LCD display via internet to achieve different functions)
Accessories	IR Remote Controller, CD ,Key
