55" Standing All In One PC Touch Screen with i3 Dual Core

Specifications

1.HDMI & VGA video input are optional
2.Designed for 24/7 operation
3.Ultra-high-fidelity sound, pleasant stereo sound





Features



• Built in media player to play almost all formats full HD multimedia files
• HDMI & VGA video input are optional
• Thief-proof
• Designed for 24/7 operation
• Ultra-thin and ultra-light transmission tempered glass or acrylic protective layer

• Fully enclosed aluminum frame ,cold-rolled steel design shell

• Industrial grade paint technology, smooth and uniform, waterproof and dustproof, anti dust and mill

• Design for both horizontal and vertical use

• Ultra-high-fidelity sound, pleasant stereo sound

• Remote controller adopt password control,access control and softdog U dish

• Support picture split ,video split ,rolling marquee,timing ON/OFF ,25days playlist setting ,ect

• Apply the newest 4G digital multimedia professor

• Long time stable operation,adopt wide viewing angel technology ,high brightness industrial LCD panel








Specification







Model	US-AD550WL
Screen Size	55 inches
Product Size(mm)	830(H)x1950(V)x150(D)
Display Size(mm)	680.4(H)x1209.6(V)
Pixel Pitch	0.63(H)x0.63(V)
Resolution	1920x1080
Brightness	700 cd / m2
Aspect Ratio	9:16
Contrast Ratio	5000:1
Viewing Angle	178°
Colors	1.07 Billion
Input Power Voltage	AC 110-240V (50Hz-60Hz)
Working Temperature	0°C - 50°C
Speakers	2×5W(9Ω)
Program Input Port	USB 2.0 x 2
Built-in Flash Memory	4GB
Signal Input Port	VGA,HDMI,Audio (3.5mm)
Power Consumption	270W
Supported Media Format	Video: All Formats (1080P Full HD) Picture: JPG,GIF,BMP,PNG Audio: All Formats
Timer On/Off	Support (Set by daily or weekly)
Scrolling Test	Support
Split Screen	Support
AD Playlist Editor	Support (software free of charge, sync with LCD digital signage via USB flash drive to achieve different functions)
Internet Control (work with software)	LAN, WIFI,3G (Optional)
Software	Optional (digital signage software to control LCD display via internet to achieve different functions)
Accessories	IR Remote Controller, CD ,Key











i3 Computer Specifications:



-CPU: Intel Core I3-2100 dual core 3.10GHz processor

-Main board: Minix H67-USB3

-Chip: Intel

-Capacity of RAM: 4G, DDR3

-Hard Disk: SATA Rev:2.5 500GB 7200RPM

-Integrated Graphics: Intel HD Graphics Family, 1317MB

-Video: Intel 6 Series Chipset High-Fidelity audio

-Network interface card: Botong Netlink BCM57788  Dual Gigabit Ethernet interface

-Mouse and keyboard: Wireless (Optional)

- Wireless card: Atheros AR9285 802.11b/g/n



Technical Parameter for IR Touch Screen



-Touch Max Resolution: 4096×4096

-Transparency: > 90%, Up to 100%

-Scanning Speed: >50Scans/S

-Response Speed: <12ms

-Touch Type: Horizontal Multi Dot Touch Screen (Vertical way is optional)

-Touch precision: 0.625mm

-Minimum Touch object: ≥5mm

-Touch Intensity: Over 60,000,000 Single Point Touch

-Operation System: DOS, WINDOWS9X/ME/2000/XP/2003/VISTA, LINUX

-Operating Voltage: DC 5V ±5%

-Power Supply: Keyboard Serial Interface

-Power: <1W (Current<200mA)

-Communication: RS-232 Interface Port, USB Port

-Vandal-Proof: Steel Ball (Diameter 63.5mm 1040g Weight) drop from 1040mm, No break

-Temperature Operating: -41°C ~70°C

-Temperature Storage: -50°C ~85°C

-Altitude: 3000m

-Noise: None

-Life Time: >10 Year
