Home > Consumer Electronics > LED Display > Indoor LED Display > 17'' All-in-one Touchscreen Lcd Monitor

17'' All-in-one Touchscreen Lcd Monitor

17'' All-in-one Touchscreen Lcd Monitor photo-1
US$ 1 - 5 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
USER/OEM
Model Number:
US-T1701HC
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name USER/OEM
Model Number US-T1701HC
Usage Indoor
Tube Chip Color Full Color
Display Function Video
Pixels Other, 0.264
Screen Dimension 17''

Specification model

Model No.

US-T1701HC

Panel size

17″TFT-LCD

Display area(mm)/mode

340(W)×273(H) 4:3

Maximum resolution

1280×1024

Display color

16.7M

Pixel Pitch(mm)

0.264(H)×0.264(V)

Brightness (nits)

300nits

Contrast

1000:1

Visual angle

170°/170°

Response time

8ms

Horizontal frequency

50-70KHZ

Vertical frequency

56-75KHZ

Life(hrs)

60,000(hrs)

Touch Panel

Specification

IR touch screen

Positioning accuracy

±1mms

Transmittance

95%

Hardness

7H

Click manner

double point

Response time

10ms

Output Resolution

4096X4096

Life time

Single point of more than 60 million

Input and output

VGA

2

DVI

2

USB2.0

6

LAN

1

PC Audio

1

PS2

1

Speaker

2×5W(8 ohm)

Video

Color system

PAL/NTSC/SECAM

Compatible HDMI input/DVI

480P,576P,720P,1080I,1080P

3D Comb filter

Yes

Video reduction noise

Yes

OSD display( screen menu display)

Menu language

Chinese/English( multiple language option required)

Computer

Main chipset

Intel G41+ICH7

Main board

ONDA G41

CPU

Intel Pentium Dual E5500 (2.8G)

System bus frequency

800/1066/1333 MHz

Graphics card

Integrated   IntelGMX 4500

Audio card

Integrated AC97

Network card

Integrated 10/100/1000M adaptive

Memory

2G DDRIII (max 4G)

Hard Disk

320G SATA

Operation system

Windows 7

Power

Power supply

AC100V~240V,50/60Hz

Maximum power consumption

35W

Standby power consumption

1W

Temperature

Working temperature

0°C~50°C

Storage temperature

-10°C~60°C

Working humidity

20%~80%

Storage humidity

5%~95%
